Specifications: Display:
4.3" 272 x 480-pixel color display with backlight
16 bit depth color
Three page views are possible
Different color icons for each function shown on the LCD
Features Keys and Indicator:
20 physical keys each with a dual-color LED
40 additional keys through page switch
3 independent control keys with illuminated LED are used for fast switching pages
Programmable for shared line, BLF List, call park,conference, forward, group pickup, group listening, LDAP, XML Browser
Features:
Wallpaper
Screensaver
Power saving
Avatar Display on SFB and UC platform (pending)
Stand with 2 adjustable angles
For support of two or three Expansion Modules, an external Yealink power adapter (5V / 2A) is required.
Up to three EXP50 can be attached on any Yealink
T5 Series IP phones:
USB port (2.0 compliant) for data in and out
USB port (2.0 compliant) for: wired / wirele...
Specifications: Standards
802.3 10BaseT
802.3u 100BaseT
802.3ab Gigabit Ethernet
Proprietary PoE
Physical Interface
1) Gigabit Data Port
(1) Gigabit Data & Power Output Port
(1) IEC-320 C6 AC Connector
Power
Input voltage : 100 to 240 VAC
Input current: 0.8A maximum for 100 VAC
AC input Frequency: 47-63Hz
Maximum output power: 32.8W
Pin4, 5:54V; Pin7, 8: Return
Temperature Range
Operating: 32 degree F to 104 degree F (0 degree C to 40 degree C)
Storage: -22 degree F to 176 degree F (-30 degree C to 80 degree C)
Humidity (non-condensing)
Operating: 5 to 90% or less
Storage: 5 to 90% or less
LED Indicator: 1 x Power on Green
Mounting: Wall (anchors & screws included)
Dimensions: 1.30" x 3.90" x 2.27"
Parts: Manufacturers Limited Warranty: 1 Year / Parts Only
