Specifications: Cable Requirements: Twisted pair: CAT5 or above, shielded or unshielded;Singlemode fiber: 50-/125-µm or 62.5-/125-µm duplex
Humidity: 5 to 95%, noncondensing
MTBF: 109k hours
Operating temperature: +32 to +122°F (+0° to +50°C)
Power: From the included external 100-240-VAC, 50-60-Hz adapter;Via USB Power Adapter Cable (LHC021A) connected to a computer's USB port;From the PowerTray with a 100-240 VAC, 50-60 Hz (LHC018A-AC-R2) power supply
Storage temperature: 0 to 160°F (-20 to +70°C)
Specifications: Connect 10BaseT/100BaseT UTP Ethernet to 100BaseFX Fiber Ethernet
Auto MDI/MDI-X
UTP port auto-senses network speed
Switch selectable half or full duplex operation on the fiber port
Fiber lengths up to 2Km
2 Power Choices - AC-DC Adapter or USB
5 LED Function lights
Uses 62.5/125 or 50/125 Multimode cable
Wavelength: 1310nm
Supports Link Fault Pass-through (LFP) for easy tracing of network link failures
Interfaces/Ports:
1 x RJ-45
1 x SC Duplex
Connectivity:
UTP
Fiber
Connectivity Media:
10/100Base-TX Category 5 UTP
10/100Base-TX Category 6 UTP
100Base-FX 50/125 µm Multi-mode Fiber
100Base-FX 62.5/125 µm Multi-mode Fiber
Package Contents:
N784-001-SC UTP to Fiber Media Converter
10/100 Media Converter, UTP - SC
AC-DC Power Adapter ( 100-240V )
Owner's Manual
