Specifications: Type: 5V 3pin ARGB LED strip LED strip length: 3.3ft LED numbers: 60 LEDs ARGB cable length: 1.64ft Installation: by double side adhesive
Specifications: Application: For Digital-RGB equipped Cases, Controllers and Motherboards. (+5V, Data, NA, GND)
Color: Full RGB color spectrum
Connections:
Input: Phanteks 3-pin (female) connector
Output: Phanteks 3-pin (male) connector
M/B Adapter: Digital RGB adapter 3pin (+5V,Data,NA,GND)
Input Voltage: +5V
Current (Single strip): Max. 0.84A
Current (Dual Strip): Max. 1.68A
Wattage (Single strip): Max. 4.2W
Wattage (Dual Strip): Max. 8.4W
Cable compatibility: For Phanteks Digital-RGB LED system, For M/B Only with Digital-RGB Pin Header (+5V,DATA,NA,GND)
LED Color/ Controller: KS6812, Full Color Digital-RGB LED Chip
LED Number: 28 LEDs (400mm NEON Digital-RGB LED Strip)
MTBF: 20,000 hrs
Product Dimensions: 400 x 13 x 5.5mm (15.7 x 0.5 x 0.2in)
Scope of Delivery:
2 x 400mm (15.7in)...
Specifications: Strip Length:19in per strip
Input Voltage:DC 5V Only support DC5V ,don't support DC12V
Waterproof Grade:IP30
Double-sided adhesive
Powered by 5V 3-pin RGB header on your computer motherboard
Please make sure it is 3-PIN RGB header on your computer motherboard before you buy this PC strip kit.
Specifications: Strip Length:19in per strip
Input Voltage:DC 5V Only support DC5V ,don't support DC12V
Waterproof Grade:IP30
Double-sided adhesive
Powered by 5V 3-pin RGB header on your computer motherboard
Please make sure it is 3-PIN RGB header on your computer motherboard before you buy this PC strip kit.
Specifications: Unit Dimension: 15.50 x 69.00 x 133.00mm
Power Input:
Logic: 2.97V to 3.63V, 4.5V to 5.5V
Fan: 11.4V to 12.6V
RGB LED: 4.5V to 5.5V
Cable:
USB: 440mm
SATA Power: 465mm
Thermal sensor: 610mm
Fan extension: 300mm
RGB LED channels: Two 2-pin connector
Max. RGB LED strip per channel: 4
Max. RGB fan per channel:6 through 1 RGB LED hub
Specifications: Color: Red
Material: Plastic strip with 15 LED(3.6W) and adhesive tape
Operating system support: 12V
Connectors:
Peripheral to LED 4pin connector x 1
4pin daisy chain connector x 1
Length: 300mm
Weight: 22g
Specifications: Color: White
Material: Plastic strip with 15 LED(3.6W) and adhesive tape
Operating system support: 12V
Connectors:
Peripheral to LED 4pin connector x 1
4pin daisy chain connector x 1
Length: 300mm
Weight: 22g
Specifications: Material 12 pcs addressable RGB LED with magnetic strip and adhesive tape
Pin definition:
+5V, D, G*
+5V, D, NP, G*
Included Parts:
2 x Addressable RGB LED strip
1 x Motherboard connect cable**
1 x Splitter cable
Length: 300mm
Wattage: 3W (5V, 0.6A)
Tandem limits: Depend on controller
Remark:
* Please check the control box and motherboard pin header that you want to connect are the same as LS03’s pin definition.
** Included Motherboard connect cable supports SilverStone’s addressable RGB 3pin connectors and other market standard addressable RGB 3pin (three pin in four pin housing) connectors.
Specifications: Color: Blue
Material: Plastic strip with 15 LED(3.6W) and adhesive tape
Operating system support: 12V
Connectors:
Peripheral to LED 4pin connector x 1
4pin daisy chain connector x 1
Length: 300mm
Weight: 22g
Specifications: LED Type: 5050 Top SMD
LEDs: 12
LED length: 30cm
Lumens: 50-60 lm
Voltage: 12V
Wattage (W): 3.6W
Accessories: Power cable x 1 Extended cable x 1
Specifications: Material Plastic Shell
Signal input:
Standard addressable RGB 3Pin +5V, D, G*
Motherboard addressable RGB 4pin +5V, D, NP, G*
Signal output: SilverStone custom addressable RGB 3pin +5V, D, G** x 8
Power Input: SATA 15pin
Output limitation (each port): 5V 9A (4.5A+4.5A)***
Included Parts:
8 x Standard addressable RGB 3pin cable
1 x SATA power cable
1 x Input signal cable
Specifications: Material: 18 pcs 5050 RGB LED with magnetic strip and adhesive tape
Pin definition: +12V, G, R, B
Included Parts:
RGB LED strip x 2
Y cable x 2
Length: 300mm
Wattage: 1.44W (12V, 0.12A)
Tandem limits: 5 pcs on each line
Weight: 30g
