Frequency Band: RF
Operating frequency* 57–71 Ghz
* Depends on regulatory region.
Channel bandwidth 2160, 1080 MHz
Polarization Vertically linear
Beamwidth Azimuth: 3 dB 1.6°
Elevation: 3 dB 1.6°
LEDs: Power Flashing white: bootup in progress
White: not connected to UISP application
Blue: connected to UISP application
Ethernet Flashing blue: Ethernet activity
GPS Blue: receiving at least (4) GPS satellite signals
60G Blue: active connection
Power Supply: Power method Passive PoE 4-pairs (1, 2+; 3, 6-) (4, 5+; 7, 8-)
Passive PoE 2-pairs (4, 5+; 7, 8-), for 44–54V DC only
Power supply 48V DC, 0.65A gigabit PoE adapter (Included)
Supported voltage range 44–54V DC
22–27V DC
Antenna: Integrated down tilt omni-directional antennas for 4x4 MIMO with peak antenna gain of 5.3 dBi in 2.4 GHz, 6.0 dBi in 5 GHz (5.8 dBi in dual-5 GHz mode) and 6.0 dBi in 6 GHz (5.9 dBi in dual-6 GHz mode). Built-in antennas are optimized for horizontal ceiling mounted orientation of the AP. The down tilt angle for maximum gain is roughly 30 to 40 degrees.
Interface: Ethernet Technology 10 Gigabit Ethernet
USB Yes
Number of Network (RJ-45) Ports 2
USB Standard USB 2.0 Type A
Management Port Yes
PoE PD Port Yes
Wireless Data Rates: Max bandwidths and peak data rate per band: 20/40 (2.4 GHz), 20/40/80 (5 GHz), 20/40/80/160 (6 GHz), and maximum peak data rate 3.6 Gbps
Frequency Band: 2.4 GHz and 5 GHz or 2.4 GHz and 6 GHz or 5 GHz and 6 GHz
Interface: Wired Network Interface: 1 x 2.5GbE, 4 x 1GbE
Ports:
Uplink (E0): Ethernet wired network port (RJ-45)
Downlink (E1-–E4): Ethernet wired network ports (RJ45)(E1 and E2: POE-PSE) USB 2.0 host interface (Type A connector)
Cellular radio module interface (accessible after removing the back cover) Serial console interface (proprietary, micro-B USB physical jack) Kensington security slot
Package Contents: ZoneFlex dual-band (5 GHz and 2.4 GHz concurrent) Wave 2 802.11ac wireless access point, 4x4:4 streams, adaptive antennas, dual ports, PoE support. Includes adjustable acoustic drop ceiling bracket. Does not include power adapter.
Wireless Data Rates: 802.11a: 6, 9, 12, 18, 24, 36, 48, and 54 Mbps
802.11b/g: 1, 2, 5.5, 6, 9, 11, 12, 18, 24, 36, 48, and 54 Mbps
802.11n data rates on 2.4 GHz: 6.5 to 300 Mbps (MCS0-MCS15, HT 20/40)
802.11ac data rates on 5 GHz: 6.5 to 867 Mbps (MCS0-MCS9)
Interface: 1 x Gigabit Ethernet uplink (10/100/1000BASE-T autosensing), PoE
3 x Gigabit Ethernet local ports (10/100/1000BASE-T), including one PoE out port:
PoE out provides 802.3af (Class 0) when access point is powered by 802.3at, or no output when powered by 802.3af
One passive pass-through port, RJ-45 (back to bottom)
