Protocols: LLDP-MED for VLAN discovery; IPv4; TCP (RFC 793) in SSL/TLS; Domain Name System (DNS): A records (RFC 1706), SRV records (RFC 2782), RTP (RFC 1889, 1890), RFC 5966
Security: HTTPS secure provisioning; Local Access Interface: IVR password
Ports: 1 RJ-45; 1 RJ-11; 1 USB 2.0 Type-A (for media and storage applications)
Specifications: Interfaces/Ports
PoE (RJ-45) Port:
No
USB:
No
Management Port:
No
Number of Network (RJ-45) Ports:
1
Number of FXS (RJ-11) Ports:
2
I/O Expansions
SIM Card Supported:
No
Network & Communication
Ethernet Technology:
Fast Ethernet
Network Standard:
10/100Base-T
Wireless Specifications
Wireless LAN:
No
Power Description
Redundant Power Supply Supported:
No
Physical Characteristics
Form Factor:
Wall Mountable
Desktop
Height:
3.9"
Width:
3.9"
Depth:
1.1"
Weight (Approximate):
4.70 oz
Specifications: Test Pin Configuration:
- RJ45 EIA, TIA-568A/568B, and crossover cables
- RJ9, RJ11, RJ12, RJ14, RJ25, RJ45, and RJ61
- USOC 2, 4, 6, and 8
- Coax Video-BNC and CATV-F
- USB 3.0, USB 2.0
Transmitter Unit Interface:
- 1 x RJ port
- 1 x USB 3.0/2.0 Type-A port
- 1 x USB 3.0/2.0 Type-B port
- Test button
- Mode button
- On/off button
- LED indicators
- Battery compartment
- Receiver unit attachment port
Power Source
- Transmitter: 9 V DC battery (not included)
- Remote unit: No power needed
Specifications: Test Services:
Graphical wiremap, length, cable ID, and distance to fault displayed on one screen.
Tests all common media types including RJ11, RJ45, Coax, with no need for adapters.
Locates virtually any cable or wire pair with IntelliTone digital and analog toning.
Verifies today's media services, including 10/100/1000 Ethernet, POTS, and PoE.
Integrated rubber holster enhances grip and makes it durable enough for the toughest jobs.
Large, backlit LCD makes results crystal clear whether in bright sunshine or in a dark closet.
Length Measurement: 11.81" to 1509 ft
Ports: RJ-45 10/100/1000Base-T Network
Connectivity Media: UTP
Display Screen: Monochrome LCD with backlight
Batteries: AA Standard
Dimensions: 3.00" x 6.40" x 1.40"
Weight (Approximate): 12.80 oz
Specifications: Audio: Yes
Cabling: Cat 5e UTP or better
Daisy-Chain: Yes
Rack-Mountable: Yes
Audio Specifications: 7.1 Channel Surround
Max Distance: 100 m / 330 ft
Maximum Digital Resolutions: 1920x1080 @60Hz
Supported Resolutions:
1920 x 1080 @60Hz
1280 x 720
1680 x 1050
1600 x 900
1440 x 900
1360 x 768
1280 x 800
1280 x 768
Lower resolutions and refresh rates may also be supported
Wide Screen Supported Yes
