Specifications: Standards and Protocols: IEEE Std 802.3, 802.3ab, 802.3bz, 82.3an
Power Supply: 3.3V
Max. Cable Length:
- 100BASE-TX: UTP cat .5 or above (max. 100m)
- 1000BASE-T/2.5GBASE-T/5GBASE-T: UTP cat.5e or above (max. 100m)
- 10GBASE-T: UTP cat.6a or above (max. 30m)
Data Rate: 10.3 Gbps
Port Type: 1 x 10G RJ45 Port
Safety & Emission: FCC, CE, RoHS
Environment:
- Operating Temperature: 0 - 70 °C (32 - 158 °F)
- Storage Temperature: -40 - 85 °C (-40 - 185 °F)
Features: Support 10GBASE-T, 5GBASE-T, 2.5GBASE-T, 1000BASE-T, and 100BASE-TX
Transmit data up to 30m* at 10 Gbps (UTP cat.6a or above)
Support DDM (Temperature and Voltage)
Hot-Pluggable SFP+ Footprint Features
Support TX Disable function
Commercial Product Operating Temperature Range: 0-70°C
Fully Metallic Enclosure for Low EMI
Standards: IEEE 802.3ae – 10 Gigabit Ethernet over fiber
IEEE 802.3x – Flow Control
IEEE 802.1Q – VLAN tagging
IEEE 802.1p – Priority tagging
IEEE 802.1qaz – Data Center Bridging (DCB) enhancements
IEEE 802.1Qbb – Priority-based Flow Control (PFC)
IEEE 802.3ap – Backplane Ethernet
RoHS Compliant – Restriction of Hazardous Substances
PCI-SIG – PCI Express 2.0 Compliance
Low Halogen –
Connectors: Port Type:
SFP+ (Small Form-factor Pluggable Plus)
– Accepts hot-swappable SFP+ transceivers
Number of Ports:
2 x 10GbE SFP+ Ports
Compatible Transceivers / Cables:
SFP+ Direct Attach Copper (DAC) cables
SFP+ SR (Short Range) Optical Modules
SFP+ LR (Long Range) Optical Modules
Connector Interface:
Standard SFP+ cages for fiber or copper
No RJ45 (not compatible with standard Ethernet cables)
PCIe Interface:
PCI Express...
Wavelength: TX wavelength*
Blue latch: 1310 nm
Yellow latch: 1550 nm
Must be used in pairs (blue latch and yellow latch).
RX wavelength*
Blue latch: 1550 nm
Yellow latch: 1310 nm
Must be used in pairs (blue latch and yellow latch).
