Specifications: Device Control:
Sony compatible RS422 deck control ports. Serial ports TxRx direction reversible under software control.
Supported Codecs:
AVC-Intra, AVCHD, Canon XF MPEG2, Digital SLR, DV-NTSC, DV-PAL, DVCPRO50, DVCPROHD, DPX, HDV, XDCAM EX, XDCAM HD, XDCAM HD422, DNxHR & DNxHD, Apple ProRes 4444, Apple ProRes 422 HQ, Apple ProRes 422, Apple ProRes LT, Apple ProRes 422 Proxy, Uncompressed 8-bit 4:2:2, Uncompressed 10-bit 4:2:2, Uncompressed 10 bit 4:4:4.
Software:
Software Included: Media Express, Disk Speed Test, LiveKey, Blackmagic Desktop Video Utility and Blackmagic driver on Mac OS and Windows. Media Express, Blackmagic Desktop Video Utility and Blackmagic driver on Linux.
Internal Software Upgrade: Firmware built into software driver. Loaded at system start or via updater software.
Physical Installation: PCI...
Specifications: RoHS Compliance Version: Yes
Length: 1M
Latch Style: Pull Type
Directional: No
Connector: SATA to eSATA
Type: Passive
Transfer Rate: 6 Gb/s
Specifications: Test for:
Tests 20-pin and 24-pin power supplies
Tests SATA power
Tests Pentium 4 power connector
Tests PCI-Express power connectors
Tests Xeon power connectors
Tests Floppy drive connectors
Tests standard 4-pin power supply connectors
Tests for +3.3V, -12V, PG, +5VSB, +12V, -5V, +5V outputs
Note:
The -5V DC output is took off from Intel ATX12V design guide since the 1.2 version.
1. The -5V usage was for last generation ISA slot. But the old ISA had been phased out since 1993~1994.
2. Neither P3 nor P4 systems will need -5V output.
