Features: Power a non-PoE device up to 100 meters (328 ft.) away
Splits a gigabit PoE signal into separate power and gigabit data sources
Adjustable voltage output supports 5V, 9V, or 12V devices
Use this compact device with PoE switches or injectors
Save on installation and equipment cost
Full Duplex Gigabit speeds
IEEE 802.3af PoE compatible
NDAA compliant
Network Media: Media Type Supported:
Twisted Pair
Ethernet Technology:
Gigabit Ethernet
Network Technology:
1000Base-T
Uplink Interface: Total Number of Network Ports:
5
Network (RJ-45):
Yes
Port/Expansion Slot Details:
4 x Gigabit Ethernet PoE+
1 x Gigabit Ethernet Network
Features: • 8 x Gigabit PoE+ ports
• Up to 200W PoE power budget
• Hardened IP50 rated metal switch
• Extreme operating temperature range of -40° – 75°C (-40° – 167°F)
• Dual inputs provide redundant power with overload current protection
• Alarm relay triggered by power failure
• 16Gbps switching capacity
• Includes DIN-Rail mount and wall mount brackets
• Power supply sold separately (model: TI-S24052)
• NDAA
Features: • Easy installation
• 4 x Fast Ethernet PoE+ ports and 2 x Fast Ethernet ports
• 1.2Gbps switching capacity
• 60W PoE budget
• Wall mountable design
• Sturdy metal switch
• Use with TRENDnet's PoE splitter to network and power non-PoE devices
• Lifetime Warranty
Features: • 8 x M12 (X-code) Gigabit PoE+ ports
• 2 x M12 (X-code) Gigabit port with Bypass function
• 1 x M12 (A-code) power port
• PoE power budget: 200W @ 56V DC / 100W @ 24V DC
• EN 50155 compliant for rolling stock and railway applications
• Hardened IP40 rated metal housing
• 20Gbps switching capacity
• Operating temperature range of -40° –
Features: • 8 x Gigabit PoE+ ports
• 2 x SFP ports
• Supports 100/1000Base-FX fiber SFP modules
• PoE power budget: 240W@48VDC or 124W@24VDC
• PoE alive check restarts unresponsive PoE powered devices
• 20Gbps switching capacity
• Hardened IP40 rated metal housing
• Includes DIN-Rail mounting bracket
• Operating temperature range of -40° – 75° C (-40° – 167° F)
• Supports LACP, STP/RSTP, VLAN, and IGMP Snooping
• IEEE 802.1p QoS with queue scheduling support
• Bandwidth control per port
• Redundant power inputs with overload current protection
• Alarm output triggered by power failure
• Power supply sold separately (models: TI-S24048, TI-S48048, TI-S24052, TI-S15052)
• NDAA / TAA compliant (U.S. and Canada only)
• Lifetime Warranty
