Ports: 5-IN-1 MULTIPORT USB C HUB
1 x USB-C Power Delivery Charging Port,
1 x USB C to HDMI Output,
2 x USB 3.0 Ports,
1 x Gigabit Ethernet port (RJ45 port)
Connector Detail: Connector A: 1 x USB-C (24 pin) DisplayPort Alt Mode Male Input
Connector B: 1 x DisplayPort (20 pin) Output
Specifications: Audio Specifications: 7.1 surround sound
Maximum Digital Resolutions: 3840x2160 @ 60 Hz
Supported Resolutions :
1024x768
1280x720 (High-definition 720p)
1920x1080 (High-definition 1080p)
1920x1200
2560x1440
2560x1600
3840x2160 (Ultra HD 4K)
Wide Screen Supported: Yes
Note:
Your USB-C equipped device must support video (DP Alt Mode) to work with this adapter.
Specifications: Connects a USB-C or Thunderbolt 3 PC, laptop or tablet to a wired Ethernet network
Provides instant access to Gigabit speeds without an internal Ethernet card
Simplified connections with a reversible Type-C connector that plugs into your device’s port in any direction
Easy to install with plug-and-play operation - no software or drivers required
Ultra-compact design for easy transport
Compatibility: Compatible with HP Elite x2 1012 G1; HP Elite x2 1012 G2; HP Pro x2 612 G2; HP EliteBook Folio G1; HP EliteBook x360 1030 G2; HP EliteBook x360 1020 G2; HP EliteBook 1040 G4; HP EliteBook 800 G5; HP EliteBook 700 G5; HP ProBook 600 G4; HP ProBook 400 G5; ZBook 14u G5; ZBook 15u G5
Ports Spec: Front: 1 USB-C port with data and power out (15W); 1 USB-C cable to connect to host system (0.7 meter cable length); Side: 1 powered USB 3.0 port; 1 combo Audio Jack; 1 Kensington lock slot; Back: 1 Thunderbolt port; 1 USB-C DisplayPort data and power out (15W) port; 2 DisplayPort ports; 1 VGA port; 2 USB 3.0 ports; 1 RJ45 port; 1 AC Adapter connector
Type: USB-C Hub with USB-A, USB-C and Power Delivery
Color: Black
Cable Length: 5 in.
Specifications: The USB-C Hub with USB-A, USB-C and Power Delivery expands USB capabilities by providing two USB-A ports and two USB-C ports for connecting peripherals to a single USB-C port. This hub connects to a USB-C or Thunderbolt 3 enabled laptop, tablet, or desktop computer and features USB-C power delivery, making it ideal for charging mobile devices or transferring data while in the office or on the road.
Convenience
Small, lightweight and portable, the hub is easily stored in a laptop case or pocket. With a transfer rate up to 5Gbps, it is fully USB 3.0 (USB 3.1 Gen 1) compliant, backwards compatible with USB 2.0 and USB 1.1 devices, and supports all USB peripherals, including keyboards and mice, smartphones, tablets, and other USB devices.
Per...
Compatibility: Windows 10 (32/64 bit), 8.1 (32/64bit), 7 (32/64bit)
Windows Server 2008 R2, 2012(32/64bit)
Mac OS 10.10 - 10.15
Ports Spec: 2 x 4K DisplayPort (DP) displays (up to 4096 x 2160p @ 60Hz)
1 x USB 3.2 Gen 1 Type-A port (5 Gbps)
1 x Gigabit Ethernet port (with PXE Boot and Wake-on-LAN support)
Specifications: Connector(s):
1 - Drive Connectors: M.2 (PCIe, SATA, M-Key, NGFF)
1 - Host Connectors: USB 3.1 USB Type C (10 pin, Gen 2, 10 Gbps)
Interface: USB 3.1 Gen 2
Bus Type: USB 3.2 Gen 2 10Gbps
Number of Drives: 1
Drive Size: 22 mm - M.2 NVMe
Compatible Drive Types: M.2 (PCIe, NVMe, M-Key, NGFF)
Drive Installation: Fixed
Compatible Drive Types: M.2 SATA (NGFF, B+M-Key)
Supported Drive Height(s):
2230
2242
2260
2280
Chipset ID: Realtek - RTL9210B
1 - LED Indicators: Power & Activity
Maximum Data Transfer Rate: 10 Gbps
Type and Rate: USB 3.2 Gen 2 - 10 Gbit/s
UASP Support: Yes
TRIM Support: Yes
4Kn Support: Yes
Type and Rate: NVMe (PCIe Gen 3)
Insertion Rating:
USB-C: 10,000 cycles
M.2: 60 Cycles
General Specifications: Fully compatible with M.2 SATA, AHCI and PCIe NVMe based drive...
Specifications: Maximum Digital Resolutions: 3840 x 2160 (Ultra HD 4K) @ 60hz
Supported Resolutions: 1024 x 768, 1280 x 720, 1920 x 1080, 1920 x 1200, 2560 x 1440, 2560 x 1600, 3840 x 2160 @ 60Hz
Wide Screen Supported: Yes
Connector A: 1 x USB-C (24 pin) Male Input
