Features: • 1 x 2.5G PoE++ port (Data + PoE out)
• 1 x 2.5G port (Data in)
• 95W PoE power budget
• Supports PoE (15.4W), PoE+ (30W), and PoE++ (95W)
devices
• Uses IEEE 802.3af, IEEE 802.3at, and IEEE 802.3bt industry
PoE standards for greater device interoperability
• Network a PoE device located up to 100m (328 ft.) away
• Fanless design eliminates operating noise and lowers energy
consumption
• Extreme operating temperature range - 40° — 75° C (-40° —
167° F)
• Redundant power inputs with overload current protection
• Includes DIN-Rail mount and wall mount
• Power supply sold separately (model: TI-S15052)
• NDAA / TAA compliant (U.S. only)
Features: • Supplies PoE (15.4W) and PoE+ (30W)
• Network a PoE device located up to 100 meters (328 ft.) away
• Converts a non-PoE gigabit port to a PoE gigabit port
• Save on installation and equipment costs
• Wall mountable for installation flexibility
• Built-in internal power supply
• IEEE 802.3af and IEEE 802.3at compliant
• NDAA / TAA compliant (U.S. and Canada only)
Specifications: Standards
IEEE 802.3
IEEE 802.3u
IEEE 802.3x
IEEE 802.3ab
IEEE 802.3af
IEEE 802.3at
IEEE 802.3bt
Device Interface
1 x Gigabit PoE++ in port
1 x Gigabit PoE+ out port
1 x Gigabit 24/48V DC passive PoE out port
LED indicators
Wall mount
IP67 housing
Data Transfer Rate
Ethernet: 10Mbps (half duplex), 20Mbps (full duplex)
Fast Ethernet: 100Mbps (half duplex), 200Mbps (full duplex)
Gigabit: 2000Mbps (full duplex)
Performance
RAM buffer: 1Mb
MAC Address Table: 2K entries
Jumbo Frame: 9KB
DIP Switch
Adjust 24/48V DC passive voltage (default 48V DC)
