Specifications: Display Style: Signal Booster
Color: Black
Connector A: DVI-I (FEMALE)
Connector B: DVI-I (FEMALE)
Interface: DVI
Package Contents: B120-000 DVI Dual Link Signal Extender
External Power Supply ( Input: 100-240V, 50/60Hz, 0.5A Output: 5V, 2A)
Screwdriver for Equalization adjustment
Owner's Manual
Specifications: Resolution:
Up to 4K@30Hz
Ethernet:
10/100/ 1000-BASE-T RJ-45 LAN
Wireless:
Miracast and Local Wi-Fi Mode: 802.11ac dual-band 3x3 MIMO
Network Bridge: 802.11ac dual-band 2x2 MIMO
Authentication
WPA-PSK (TKIP)
Protocol:
WPA2-PSK (AES)
PEAP-MSCHAP V2
EAP-TLS
Content Protection:
HDCP 2.x
Power:
Input: 12VDC, 3A
Consumption: 8.4W (typical), 36W (peak)
Dimensions:
8.66 x 5.66 x 1.47 inch (220 x 144 x 37.5 mm)
Operating temperature:
0º - 40º C (32º - 104º F)
Storage temperature:
-20º - 85º C (-4º - 185º F)
Operating humidity:
20 - 80% non-condensing
Storage humidity:
10 - 90% non-condensing
Language support:
English
Simplified Chinese
Traditional Chinese
Japanese
French
German
Dutch
Korean
Spanish
Italian
Russian
Regulatory and compliance:
Approved: FCC and UL
Pending: CE, RoHS and C-Tick
Interface: 1 x HDMI Input
1 x HDMI Output
2 x USB 2....
Specifications: Supported APIs:
Windows
- DirectShow
- DirectKS
- Wave API/DirectSound/WASAPI
Linux
- V4L2
- ALSA
Supported Software
VLC
VirtualDub
OBS
xSplit
vMix
VidBlaster
Wirecast
Microsoft Media Encoder
Adobe Flash Media Encoder
Any other DirectShow/V4L2 encoding/streaming software
Input Features
Support for input video resolutions up to 2048x2160 pixels
HDMI Specific Features:
225MHz HDMI receiver
Adaptive HDMI equalizer support for cables lengths up to 30M
Support for customized EDID
Support for extraction of AVI/Audio/SPD/MS/VS/ACP/IRSC1/ISRC2/ Gamut InfoFrames
Full colorimetry support
Support for 8/10/12-bit color depths
Support for RGB 4:4:4, YCbCr 4:4:4, YCbCr 4:2:2 color sampling
Support for up to 8-channel IEC60958/IEC61937 audio streams
Support for extraction of audio formation information & channel status data
Supp...
Specifications: Video compression:
H.264 (MPEG-4 Part 10/AVC) Baseline, Main and High Profiles
H.265 (MPEG-H Part 2/HEVC) Main Profile Motion JPEG
Resolution:
176x144/176x120 (PAL/NTSC) to 720x576/720x480 (PAL/NTSC)
Frame rate:
25/30 fps in all resolutions
Up to 30 fps in quad view in full resolution
Video streaming:
Multiple, individually configurable streams in H.264, H.265 and
Motion JPEG
Axis Zipstream technology in H.264 and H.265
Controllable frame rate and bandwidth
VBR/MBR H.264/H.265
Quad view
Power:
8-28 V DC, max 4.7 W
Power over Ethernet (PoE) IEEE 802.3af/802.3at Type 1 Class 3
Connectors:
Four analog composite video BNC input
RJ45 10BASE-T/100BASE-T/1000 BASE-T PoE
RS485/RS422, 2 pcs, 2 pos, full duplex, terminal block
Storage:
...
