Specification: Switches
DIP: 1 x Auto Switch ON / OFF
Video Input
Interfaces: 8 x HDMI Type A Female (Black)
Impedance: 100 ohm
Max. Distance: 5M at 4096 x 2160 / 3840 x 2160 @ 60Hz (4:4:4)
Video Output
Interfaces: 1 x HDMI Type A Female (Black)
Impedance: 100 ohm
Max. Distance: 5M at 4096 x 2160 / 3840 x 2160 @ 60Hz (4:4:4)
Video
Max. Data Rate: 18 Gbps (6 Gbps Per Lane)
Max. Pixel Clock: 600 MHz
Compliance:
- HDMI 2.0 (3D, Deep Color)
- HDCP 2.2
- Consumer Electronics Control (CEC)
Max. Resolution: Up to 4096 x 2160 / 3840 x 2160 @ 60Hz (4:4:4)
Max. Distance: 5M at 4096 x 2160 / 3840 x 2160 @ 60Hz (4:4:4)
Control
RS-232:
- Connector: 1 x DB-9 Female (Black)
- Baud Rate: 19200, Data Bits: 8, Stop Bits:1, Parity: No, Flow Control: No
IR: 1 x Mini Stereo Jack Female (Black)
Connectors
Power: 1 x DC Jack (with locking)
...
Specifications: Input : 1x VGA 15HDF interface input (Computer/TV Box/PS3 / PS4/DVD Player and other VGA devices) Output: 2-VGA 15HDF (Projectors/TV/Monitors etc) Video bandwidth: 250 MHz Transmission distance :100ft/30m High video resolution: 1920 x 1440 @ 60Hz Compatible with DDC, DDC2, DDC2B ( only Port 1) Support VGA, XGA, SVGA, UXGA, WUXGA and multisync monitors Important Notes: This VGA Splitters can only duplicate images from a computer to two monitors Need to set the same screen resolution,Can not support the different resolution on different screen Recommend use the monitor not more than 19'' Recommend use the vga cable which is 3+6
