Partaker Industrial Embedded Computer, Fanless Mini PC, J3710, B3, 2 x LAN, DP, 2 x HDMI, 6 x USB, COM RS232, 4G RAM, 128G SSD
- Fanless & Durable Build All-aluminum alloy housing with passive cooling, ideal for dusty, vibration-prone, or high-temperature industrial environments. Silent operation and extended lifespan.
- Triple Independent Display Supports three screens simultaneously via two high-definition digital video ports and one DisplayPort. Perfect for control rooms, digital signage, and multi-tasking workstations.
- Dual Gigabit LAN & Rich I/O Two Gigabit Ethernet ports for network redundancy or firewall applications. Includes 6 USB ports (2x USB 3.0 + 4x USB 2.0), one RS232 COM port, and audio line-out/mic combo.
- Expandable Storage & Connectivity Internal 2.5" HDD/SSD bay plus one mSATA slot. One full-size Mini PCIe socket supports 4G, Wi-Fi, or BT; onboard Nano SIM card slot ready.
- Wide Temperature & Flexible Mounting Operates reliably from -20°C to +50°C. Supports VESA, wall mount, or optional DIN-rail installation. Features auto power-on, wake-on-LAN, PXE boot, watchdog timer, and TPM2.0 security.
+
+
Overview
Specs
Reviews
Any questions? Our AI beta will help you find out quickly.
Try me now
Model Number: Partaker B3
Material: All-aluminum alloy structure, fanless cooling design
CPU: Pentium Processor J3710 2M Cache, up to 2.64 GHz
Memory: 1 x SO DIMM DDR3L-1600, MAX. 8GB RAM
Storage: 1 x mSATA SSD, 1 x 2.5 Inch SATA SSD/HDD
Network: 2 x RTL8111H
Expansion: 1 x Full Length Mini PCIE for WiFi/4G, with Nano SIM slot
Optional Expansion: 936V wide voltage power, CAN module etc(Pay extra, contact us for customize if need)
I/0 Port: SW, 2 x USB 3.0, 4 x USB 2.0, COM RS232, Audio, 2 x LAN, DP, 2 x HDMI, DC_IN
Power Supply: DC100-240V AC/50-60Hz, DC 12V 3.3A
Operating Temperature: -20°C ~ +50°C, surface air flow
Working Humidity: 5%~95% non-condensing
Size: 142 x 126.5 x 42mm
Weight: 0.74 kgs
Consumption: 6.5W
Cooling system: Fanless
Function: Power-on, Timing boot, Wake on LAN, PXEboot, Powe watchdog (level 0-255), TPM 2.0 securityencryption
Packing List: Embedded computer, power supply, power cord, vesa mount, warranty card
Installation: Supports Desktop, Din Rail, VESA wall-mounted and other fixing methods, default as vesa mount method,
if need Din Rail, please contact us or leave us message after order placed.
System Support: Windows 10/11, Linux Ubuntu
System Default Option: Windows 11 pro in English
Application: Industrial Automation, Medical, Logistics&Transportation, Warehousing, e-education and other fields.
ATTENTION: Other options, Linux or other system, other system language, do leave us message on the order, thank you.
Material: All-aluminum alloy structure, fanless cooling design
CPU: Pentium Processor J3710 2M Cache, up to 2.64 GHz
Memory: 1 x SO DIMM DDR3L-1600, MAX. 8GB RAM
Storage: 1 x mSATA SSD, 1 x 2.5 Inch SATA SSD/HDD
Network: 2 x RTL8111H
Expansion: 1 x Full Length Mini PCIE for WiFi/4G, with Nano SIM slot
Optional Expansion: 936V wide voltage power, CAN module etc(Pay extra, contact us for customize if need)
I/0 Port: SW, 2 x USB 3.0, 4 x USB 2.0, COM RS232, Audio, 2 x LAN, DP, 2 x HDMI, DC_IN
Power Supply: DC100-240V AC/50-60Hz, DC 12V 3.3A
Operating Temperature: -20°C ~ +50°C, surface air flow
Working Humidity: 5%~95% non-condensing
Size: 142 x 126.5 x 42mm
Weight: 0.74 kgs
Consumption: 6.5W
Cooling system: Fanless
Function: Power-on, Timing boot, Wake on LAN, PXEboot, Powe watchdog (level 0-255), TPM 2.0 securityencryption
Packing List: Embedded computer, power supply, power cord, vesa mount, warranty card
Installation: Supports Desktop, Din Rail, VESA wall-mounted and other fixing methods, default as vesa mount method,
if need Din Rail, please contact us or leave us message after order placed.
System Support: Windows 10/11, Linux Ubuntu
System Default Option: Windows 11 pro in English
Application: Industrial Automation, Medical, Logistics&Transportation, Warehousing, e-education and other fields.
ATTENTION: Other options, Linux or other system, other system language, do leave us message on the order, thank you.
