Partaker Fanless Industrial Embedded Computer, Mini PC, N100, I22, 2 x LAN, 2 x HDMI, VGA, DC 12V, 4 x COM, 6 x USB, 8G RAM, 128G SSD
- Powerful Quad-Core Processor (Up to 3.4GHz) 12th Gen Alder Lake-N N100 with integrated UHD graphics. Supports DDR4 3200MHz memory (up to 16GB) and triple independent 4K displays via 2x high-definition ports (4096x2160@60Hz) + 1x VGA. Ideal for industrial automation, medical, logistics, and e-education.
- Fanless All-Aluminum Cooling Design Completely silent, dust-proof, and maintenance-free. Operates reliably from -20 to +50 with surface airflow. Perfect for harsh environments where moving parts fail. Long lifespan.
- Versatile Expansion & Connectivity 1x M.2 2280 M-key slot (supports SATA & PCIe 3.0x1 NVMe SSD) + 1x full-length Mini PCIe slot (supports 4G/WiFi/Bluetooth, optional) + internal Nano SIM card slot. Supports SSD and wireless/4G simultaneously. Also features a 2.5 SATA HDD bay.
- Rich I/O & Industrial Interfaces Dual Gigabit Ethernet ports, 4x USB 3.0, 2x USB 2.0, 4x COM (RS232/485 optional on COM1/2), audio jack (line-out/mic combo). Ready for factory automation, transportation, warehousing, and IoT gateways.
- Flexible Power & Management Wide DC 12V input (5.5*2.5mm barrel). Supports wake-on-LAN, PXE boot, timing boot, watchdog timer (0-255 level), and TPM 2.0 security encryption. Mounting options: VESA, wall mount, or DIN-rail (optional). Compact size 186x127x66mm, 1.36kg.
+
+
Overview
Specs
Reviews
Any questions? Our AI beta will help you find out quickly.
Try me now
Model Number: Partaker I22
Processor: Intel N100 (4 core 4 threads, Turbo 3.4 GHz)
Chipset: Alder Lake-N
Memory: 1 x DDR4 3200MHz SODIMM, max 16 GB
Storage: 1 x M. 2 2280 M-key PCIE 3.0 x1 SATA/NVME SSD, 1 x 2.5 Inch SATA SSD/HDD
Graphics: Intel UHD Graphics
Display: 2 x HDMI(Resolution 3840 x 2160@60Hz), 1 x VGA (Resolution 1920 x 1080 @ 60Hz)
Lan Port: 2 x RTL8111H Gigabit Lan
I/O: Power Switch, 4 x USB 3.0, 4 x COM COM1 COM2 for RS232/485, Audio, 2 x USB 2.0, 2 x LAN, 2 x HDMI, VGA, DC_IN
Expansion: Full Length Mini PCIE for WiFi/4G, with Nano SIM slot
More Function: Power-on, Timing boot, Wake on LAN, PXE, watchdog (level 0-255), TPM 2.0 security encryption
Power Supply: 1 x DC( 5.5 * 2.5 mm), support 12V input
Size: 186 x 127 x 66 mm
Weight: 136KGs
Installation: VESA, Wall mount, DIN-rail (optional)
Temperature: -20°C ~ +50°C, surface air flow
Humidity: 5%~95% non-condensing
System Support: Windows 11, Linux Ubuntu
Optional Expansion: 936V wide voltage power, GPIO, CAN module, COM etc(Contact us if need, pay extra cost)
Cooling system: All-aluminum alloy structure, fanless cooling design
Application: Industrial Automation, Medical, Logistics &Transportation, Warehousing, e-education and other fields.
Packing List: Embedded computer, power supply, power cord, mount bracket, warranty card
Installation: Supports Desktop, Din Rail, wall-mounted and other fixing methods, default as vesa mount method. if need Din Rail, please contact us after order placed.
Processor: Intel N100 (4 core 4 threads, Turbo 3.4 GHz)
Chipset: Alder Lake-N
Memory: 1 x DDR4 3200MHz SODIMM, max 16 GB
Storage: 1 x M. 2 2280 M-key PCIE 3.0 x1 SATA/NVME SSD, 1 x 2.5 Inch SATA SSD/HDD
Graphics: Intel UHD Graphics
Display: 2 x HDMI(Resolution 3840 x 2160@60Hz), 1 x VGA (Resolution 1920 x 1080 @ 60Hz)
Lan Port: 2 x RTL8111H Gigabit Lan
I/O: Power Switch, 4 x USB 3.0, 4 x COM COM1 COM2 for RS232/485, Audio, 2 x USB 2.0, 2 x LAN, 2 x HDMI, VGA, DC_IN
Expansion: Full Length Mini PCIE for WiFi/4G, with Nano SIM slot
More Function: Power-on, Timing boot, Wake on LAN, PXE, watchdog (level 0-255), TPM 2.0 security encryption
Power Supply: 1 x DC( 5.5 * 2.5 mm), support 12V input
Size: 186 x 127 x 66 mm
Weight: 136KGs
Installation: VESA, Wall mount, DIN-rail (optional)
Temperature: -20°C ~ +50°C, surface air flow
Humidity: 5%~95% non-condensing
System Support: Windows 11, Linux Ubuntu
Optional Expansion: 936V wide voltage power, GPIO, CAN module, COM etc(Contact us if need, pay extra cost)
Cooling system: All-aluminum alloy structure, fanless cooling design
Application: Industrial Automation, Medical, Logistics &Transportation, Warehousing, e-education and other fields.
Packing List: Embedded computer, power supply, power cord, mount bracket, warranty card
Installation: Supports Desktop, Din Rail, wall-mounted and other fixing methods, default as vesa mount method. if need Din Rail, please contact us after order placed.
