NEW ROCKFORD FOSGATE P1S4-10 10" 500 Watt 4-Ohm Car Audio Subwoofer Sub P1S410

We are an Authorized Rockford Fosgate Dealer!


The **ROCKFORD FOSGATE P1S4-10** 10" 500 Watt 4-Ohm Car Audio Subwoofer is the first in a family of world famous subwoofers called "The Punch". During their inception in the 1980's, they quickly became "The Woofer of Choice" for fanatic car audio systems, with a continued tradition today. Kevlar fiber reinforced paper cones deliver bass impact you can feel, and VAST technology increases surface cone area up to 25%. Best in standard sealed and vented enclosures. Includes soft touch ABS tri trim ring.

This sub also features a flex fit basket that allows for fine tuning the sub's mounting position, and anodized aluminum voice coil which provided superior heat dissipation (up to 100° at full power levels), stitched tinsel leads which improve reliability and performance by reducing fatigue and possible shorting, a protected PVC textured magnet cover, and a StampCast basket with integrated spider venting. Choose the ROCKFORD FOSGATE P1S4-10 10" 500 Watt 4-Ohm Car Audio Subwoofer for your car audio system!


Read the Owner's Manual [here][1]

Read the Data Sheet [here][2]


[1]: https://www.rockfordfosgate.com/rftech/library/2011/5_Subwoofers/4020119-0_P1Subs-MAN_Rev2.pdf
[2]: https://www.rockfordfosgate.com/rftech/library/2011/5_Subwoofers/RFPB_P1S4-10-TS_RevD.pdf

• NEW **ROCKFORD FOSGATE P1S4-10** 10" 500 Watt Car Audio Subwoofer
• MAX Power Handling: 500 Watts
• RMS Power Handling: 250 Watts
• Linear spider with embedded 16 AWG tinsel leads
• High-temp voice coil with spun-laced Nomex® re-inforcement collar
• Kevlar fiber reinforced paper cone
• StampCast basket with integrated spider venting
• Soft touch ABS trim ring with optional grille
• Custom 10-AWG nickel plated push terminals
• Extended pole piece and bumped vented backplate
• Protective PVC textured magnet cover
• **Specifications:**
• Size: 10"
• Nominal Impedance: 4-Ohm
• Voice Coil Diameter: 2.0" (51.6 mm)
• Magnet Weight (oz): 45 oz. (1.28 kg.)
• Speaker Connector: Dual 10 AWG compression
• Fs (Hz): 30
• Re (Ohms): 3.60
• Le (mH): 2.8
• Qms: 3.00
• Qes: 0.61
• Qts: 0.51
• Vas (Liters): 40
• Sd (cm2): 370
• SPL (dB @ 1w/1m): 85
• Xmax (mm): 9.4
• Woofer Displacement (in): 0.085 cu. ft. (2.4 Liters)
• Cutout Diameter (in): 9.14 in. (232 mm)
• Mounting Depth (in): 5.33 in. (135.4 mm)
• CEA-2031 Compliant
• Weight: 10.9 lbs
• Product Condition: BRAND NEW!
• Part Number: **P1S4-10**
• Warranty: 2 Year VMInnovations Warranty
