|Type||DP to DVI|
|Specifications||Input Video: displayport 1.2,backword displayport 1.1|
Output Video: DVI 1.0
Maximum clock rate: 225MHz
Input Video Signal: 5 Volts p-p (TTL)
Maximum Resolution: 1920 x 1080 @60Hz/1920 x 1200
Power consumption (Max):1W
External Power Supply: No external power needed
Operating Temperature: 0 Degree C to +70 Degree C
Operating Humidity: 10% to 85 % RH (no condensation)
Storage Temperature: -10 Degree C to +80 Degree C
Storage Humidity: 5% to 90 % RH (no condensation)
|Connector A||1x DVI-D female|
|Connector B||1x DisplayPort male|
|Features||The Active Adapter converts DisplayPort signal to Single Link DVI,Working with video cards not capable of outputting DP++ (multi-mode) signals.|
Idea for ATI AMD Eyefinity configurations.
Displayport active adapter, support Multi-Stream Transport (MST)
Compliant with DP v 1.2 and DVI 1.0
Supports DisplayPort1.2 4 lanes.
Enables ATI Eyefinity multiple-display configurations with more than 2 Displays,supports up to 6 displays (depending on Graphics card)
DVI compliant with maximum data rate 2.25Gbps.
Supports full HD 1080P and 1920x1200 (reduced blanking) for Computers
Supports multiple color format:RGB 6/8/10/12-bit per component(bpc) and YCbCr4:4:4, YCbCr4:2:2,8/10/12bpc
Integrated both HDCP Rx and Tx keys to support HDCP repeater.
Plug and Play, No Software to Install
Power by DisplayPort source,no external Power needed
AMD Eyefinity technology is a solution developed by AMD that allows consumers to run up to six simultaneous displays off of a single graphics card. This is a unique feature of AMD graphics products that cannot be found on any other consumer graphics solution at this time.
|Date First Available||September 01, 2020|
