Ruckus Wireless - 901-R850-US00 - Ruckus R850 - Wireless Access Point - ZigBee - Bluetooth, ZigBee, Wi-Fi 6 - 2.4 GHz, 5 GHz

Ruckus R850 - Wireless access point - ZigBee, 802.11ax - Bluetooth, ZigBee, Wi-Fi - Dual Band - wall / ceiling mountable

The R850 is based on the latest Wi-Fi standard, Wi-Fi 6, which bridges the performance gap from gigabit Wi-Fi to multi-gigabit Wi-Fi in support of the insatiable demand for better and faster Wi-Fi. The RUCKUS R850 is highest capacity dual-band, dual-concurrent Wi-Fi 6 access point (AP) that supports 12 spatial streams (8x8:8 in 5GHz, 4x4:4 in 2.4GHz). The R850, with OFDMA, TWT and MU-MIMO capabilities, efficiently manages up to 1,024 client connections with increased capacity, improved coverage and performance in ultra-high dense environments. Furthermore, a 5 Gbps multi-gigabit Ethernet port mitigates backhaul capacity bottlenecks.

Additionally, the R850 is IoT- and LTE-ready, and supports wireless standards beyond Wi-Fi in combination with the RUCKUS IoT Suite and CBRS/OpenG modules. The R850 addresses the increasing client demands in transit hubs, auditoriums, stadiums, conference centers, and other highly trafficked indoor spaces. It is the perfect choice for data intensive streaming multimedia applic

• Connect More Devices Simultaneously - Improve device performance, by enabling more simultaneous device connections with built-in 8 spatial streams (dual-concurrent, 8x8:8 in 5GHz, 4x4:4 in 2.4GHz), MU-MIMO and OFDMA technology while enhancing non-Wi-Fi 6 client performance. Support for up to 1,024 clients
• Ultra-High-Density Performance - Provides exceptional end-user experience within stadiums, large public venues, convention centers and school auditoriums with the RUCKUS Ultra-High-Density Technology Suite
• Enhanced Security - Reinforce security with WPA3, the latest Wi-Fi security standard and receive enhanced protection from man-in-the-middle attacks
• Multi-Gigabit Access Speeds - Optimized multi-gigabit Wi-Fi performance delivered using built-in 5GbE/2.5GbE Ethernet ports to connect to multi-gigabit switches.
• Device Management Options - Manage the R850 with on-premises physical/virtual appliances or the cloud.
• Better Mesh Networking - Minimize complexity by reducing expensive cabling with SmartMesh that dynamically creates self-forming, self-healing mesh networks.
• Automate Optimal Throughput - ChannelFly dynamic channel technology uses machine learning to automatically find the least congested channels. You always get the highest throughput the band can support.
• More than Wi-Fi - Support services beyond Wi-Fi with RUCKUS IoT Suite, Cloudpath security and onboarding software, SPoT Wi-Fi locationing engine, and RUCKUS analytics.
• Specifi

Specifications

• Antenna Patterns, per band: 4000+
• Antenna Gain: Up to 2 dBi
• BeamFlex: Yes
• ChannelFly: Yes
• Concurrent Users: 1024
• Controller Support: RUCKUS Cloud | RUCKUS SmartZone | RUCKUS ZoneDirector | Standalone
• Ethernet Ports: 1 x 1 / 2.5 / 5 GB/s | 1 x 1 GbE
• IoT Support: IoT Onboard
• PD-MRC: Yes
• PHY Rate at 2.4 GHz, maximum: 1148 Mb/s
• PHY Rate at 5 GHz, maximum: 4800 Mb/s
• Radio Chains and Streams: 8x8:8 SU-MIMO and MU-MIMO
• Rx Sensitivity at 2.4 GHz: -91 dBm
• Rx Sensitivity at 5 GHz: -91 dBm
• SmartMesh: Yes
• USB: USB 2.0
• Venue Type: Hospitality | Public Venue | Transportation
• Venue Sub-Type: Convention Floor | Lecture Hall | Transit Stations | Venue Common Spaces
• Wi-Fi Interface Standard: IEEE 802.11a/b/g/n/ac/ax
• Wi-Fi Interface Standard at 2.4 GHz: 802.11ax
• Wi-Fi Interface Standard at 5 GHz: 802.11ax
