Shuttle XPC SX58H7-PRO Intel Socket B(LGA1366) Intel X58 Barebone
- Intel Core i7 processors (Socket 1366) Intel Socket B(LGA1366)
- Intel X58 ICH10R
- 4 x 240Pin DIMM DDR3 1600(OC)/1333/1066
- none
Specs
Reviews (10)
Any questions? Our AI beta will help you find out quickly.
Try me now
Learn more about the Shuttle Computer SX58H7-PRO
| Brand | Shuttle |
|---|---|
| Series | XPC |
| Model | SX58H7-PRO |
| Color | Black |
| CPU Type | Intel Core i7 processors (Socket 1366) |
|---|---|
| CPU Socket | Intel Socket B(LGA1366) |
| North Bridge | Intel X58 |
|---|---|
| South Bridge | ICH10R |
| Memory slot | 4 x 240Pin DIMM |
|---|---|
| Memory Type Supported | DDR3 1600(OC)/1333/1066 |
| Max Memory Supported | 16GB |
| PCI Express 2.0 x16 | 2 |
|---|---|
| Other | 1 x Mini-PCIe x1 slot |
| Serial ATA | 2 x SATA 3.0Gb/s + 2 x SATA 6.0Gb/s |
|---|---|
| SATA RAID | RAID 0/1/5/10 |
| Onboard Video | none |
|---|
| Onboard Audio | Realtek ALC888 |
|---|---|
| Channel | 8-CH |
| First LAN | Realtek 8111E(10/100/1000Mbps) |
|---|---|
| Second LAN | Realtek 8111E(10/100/1000Mbps) |
| Max LAN Speed | Dual 10/100/1000Mbps |
| 3.5" Internal bays | 1 |
|---|---|
| 3.5" External bays | 1 |
| 5.25" External bays | 1 |
| Front USB | 2 x USB 3.0 |
|---|---|
| Front e-SATA Ports | eSATA / USB 2.0 combo port |
| Front Audio Ports | 2 jacks |
| Rear USB | 8 x USB 2.0 |
|---|---|
| Rear e-SATA Ports | 1 |
| RJ45 | 2 |
| Rear S/PDIF Out | Optical S/PDIF Output |
| Rear Audio Ports | 5 jacks |
| Input | AC input voltage: 100~240V |
|---|---|
| Power Supply | 500 Watt mini PSU |
| Dimensions | 12.83" x 8.2" x 7.72" |
|---|---|
| Weight | 8.38 lbs. |
| Features | The fastest connection to external peripheral devices available to date The interface for the fastest of memory media High-performance processor from the market leader 8-channel HD audio Dual-slot graphic cards? No problem! Intelligent cooling Cleverly hidden Breathtaking 3D graphics and increased screen area Almost limitless memory External eSATA port For a longer life and more system stability A match for software heavyweights Generous supply of USB ports Pre-assembled cabling saves time |
|---|
| First Listed on Newegg | May 23, 2011 |
|---|
