SICK DT50-P1113 Mid Range Distance Sensors New

PERFORMANCE
Measuring range
200 mm ... 10,000 mm, 90 % remission
200 mm ... 6,500 mm, 18 % remission
200 mm ... 4,000 mm, 6 % remission
Target Natural objects
Resolution 1 mm
Repeatability = 2.5 mm 1) 2) 3)
Accuracy ± 10 mm 4)
Response time 20 ms ... 30 ms, 20 ms / 30 ms 3) 5)
Output time = 4 ms 6)
Light source Laser, red
Laser class 2 (IEC 60825-1:2014, EN 60825-1:2014) 7)
Typ. light spot size (distance) 15 mm x 15 mm (10 m)
Additional function Set moving average: fast/slow, switching mode: distance to object (DtO), teach-in, scaling and inversion of switching output, set hysteresis, teach-in, scaling and inversion of analog output, Multifunctional input: laser off / external teach / deactivated, switch-off display, reset to factory default, lock user interface
Average laser service life (at 25 °C) 100,000 h

INTERFACES
MECHANICS/ELECTRONICS
Supply voltage Vs DC 10 V ... 30 V 1) 2)
Ripple = 5 Vpp 3)
Power consumption = 2.1 W 4)
Initialization time = 250 ms
Warm-up time = 15 min
Housing material
Housing zinc die cast (ZNAL4CU1)
Acrylic glass (PMMA)
Connection type Male connector, M12, 5-pin
Indication LC display, 2 x LED
Weight 200 g
Enclosure rating IP65
Protection class III
