SICK LL3-DV05 Proximity system ,New
- SICK LL3-DV05 Proximity system ,New
+
+
Overview
Specs
Reviews
Any questions? Our AI beta will help you find out quickly.
Try me now
FEATURES
Device type Fibers
Detection principle Proximity system
For fiber-optic sensor GLL170(T), WLL180T, WLL24 Ex
Fiber length 2 m
Fiber material Polymethylmethacrylat (PMMA)
Jacket material Polyethylen (PE)
Fiber head material Polyamid (PA)
Outer diameter, fiber-optic cable connection 2.2 mm
Fiber-optic cable cuttable ? 1)
Thread size M6
Fiber-optic head design Threaded sleeve, 90° deflection
Fiber arrangement Monofiber
Core structure Monofiber
Bend radius, fibre-optic cable 25 mm
Angle of dispersion < 60° Yes
Compatibility with infrared light (1,450 nm) No
Ambient operating temperature –40 °C ... +70 °C
Highly flexible/elastic fibers (bend radius 1–4 mm) No
Adapter end sleeves required No
Angle of dispersion 15.94°
Integrated lens Yes
Minimal object diameter 0.015 mm 2)
Special features 90° deflection integrated, minimum insertion depths
Included with delivery Mounting, 1 x M6 hexagon nut, FC fiber cutter (5304141)
Compatibility tip adapters No
MECHANICS/ELECTRONICS
Bend radius, fibre-optic cable 25 mm
Ambient operating temperature –40 °C ... +70 °C
Device type Fibers
Detection principle Proximity system
For fiber-optic sensor GLL170(T), WLL180T, WLL24 Ex
Fiber length 2 m
Fiber material Polymethylmethacrylat (PMMA)
Jacket material Polyethylen (PE)
Fiber head material Polyamid (PA)
Outer diameter, fiber-optic cable connection 2.2 mm
Fiber-optic cable cuttable ? 1)
Thread size M6
Fiber-optic head design Threaded sleeve, 90° deflection
Fiber arrangement Monofiber
Core structure Monofiber
Bend radius, fibre-optic cable 25 mm
Angle of dispersion < 60° Yes
Compatibility with infrared light (1,450 nm) No
Ambient operating temperature –40 °C ... +70 °C
Highly flexible/elastic fibers (bend radius 1–4 mm) No
Adapter end sleeves required No
Angle of dispersion 15.94°
Integrated lens Yes
Minimal object diameter 0.015 mm 2)
Special features 90° deflection integrated, minimum insertion depths
Included with delivery Mounting, 1 x M6 hexagon nut, FC fiber cutter (5304141)
Compatibility tip adapters No
MECHANICS/ELECTRONICS
Bend radius, fibre-optic cable 25 mm
Ambient operating temperature –40 °C ... +70 °C
