SICK VS/VE12-2N132 Through-beam photoelectric sensor ,NPN New
- SICK VS/VE12-2N132 Through-beam photoelectric sensor ,NPN New
+
+
Overview
Specs
Reviews
Any questions? Our AI beta will help you find out quickly.
Try me now
FEATURES
Sensor/ detection principle Through-beam photoelectric sensor
Housing design (light emission) Cylindrical
Housing length 55.3 mm
Thread diameter (housing) Round connector M12 x 1
Sensing range max. 0 m ... 5 m
Sensing range 0 m ... 4 m
Type of light Infrared light
Light source LED 1)
Light spot size (distance) Ø 100 mm (4 m)
Angle of dispersion Approx. 1.4°
Wave length 880 nm
Adjustment None
MECHANICS/ELECTRONICS
Supply voltage 10 V DC ... 30 V DC 1)
Ripple = 10 % 2)
Power consumption 20 mA 3)
Switching output NPN
Switching mode Light/dark switching
Switching mode selector Selectable via L/D control cable
Output current Imax. = 100 mA 3)
Response time = 2 ms 4)
Switching frequency 250 Hz 5)
Connection type Cable, 4-wire, 2 m 6)
Cable material PVC
Conductor cross-section 0.14 mm²
Cable diameter Ø 3.75 mm
Circuit protection
A 7)
B 8)
C 9)
D 10)
Protection class III
Weight 108 g
Housing material Metal, Nickel-plated brass/PA
Optics material Plastic, PMMA
Enclosure rating IP67
Ambient operating temperature –25 °C ... +70 °C
Ambient storage temperature –25 °C ... +70 °C
Sensor/ detection principle Through-beam photoelectric sensor
Housing design (light emission) Cylindrical
Housing length 55.3 mm
Thread diameter (housing) Round connector M12 x 1
Sensing range max. 0 m ... 5 m
Sensing range 0 m ... 4 m
Type of light Infrared light
Light source LED 1)
Light spot size (distance) Ø 100 mm (4 m)
Angle of dispersion Approx. 1.4°
Wave length 880 nm
Adjustment None
MECHANICS/ELECTRONICS
Supply voltage 10 V DC ... 30 V DC 1)
Ripple = 10 % 2)
Power consumption 20 mA 3)
Switching output NPN
Switching mode Light/dark switching
Switching mode selector Selectable via L/D control cable
Output current Imax. = 100 mA 3)
Response time = 2 ms 4)
Switching frequency 250 Hz 5)
Connection type Cable, 4-wire, 2 m 6)
Cable material PVC
Conductor cross-section 0.14 mm²
Cable diameter Ø 3.75 mm
Circuit protection
A 7)
B 8)
C 9)
D 10)
Protection class III
Weight 108 g
Housing material Metal, Nickel-plated brass/PA
Optics material Plastic, PMMA
Enclosure rating IP67
Ambient operating temperature –25 °C ... +70 °C
Ambient storage temperature –25 °C ... +70 °C
