SIIG ID-SC0G11-S1 CyberX Industrial Rugged 4-port RS-232 USB to Serial Converter - Wide Temperature

Be the first to review this product...

Overview

Specs

Reviews

Any questions? Our AI beta will help you find out quickly.

Try me now

MAIN OVERVIEW FEATURES: Platform Supported: PCNumber of USB Ports: 1Form Factor: ExternalHeight: 5.7"Width: 1"Depth: 3.7"Weight (Approximate): 12.64 ozPackage Contents: Industrial Grade USB to 4-port RS-232 Serial Converter USB Cable (A to B) Power Adapter Wall-Mounting Kit Round Screws (M3x3, 8pcs) 2-Pin Terminal Block DB62 to 4xDB9 Console Cable Driver CD Installation guide Environmentally Friendly: YesEnvironmental Certification: RoHSCountry of Origin: TaiwanLimited Warranty: 5 Year

SIIG's CyberX Industrial Rugged 4-port RS-232 USB to Serial Converter - Wide Temperature is an industrial grade USB plug-and-play adapter hub, designed to quickly add four high speed RS-232 serial ports to desktop or notebook computers. This industrial grade USB to serial adapter hub supports serial port data transfer rate of up to 921.6 Kb/s, with a wide operating temperature range from -40?F to 158?F (-40?C to 70?C) - perfect for harsh industrial environments.

The CyberX Industrial Rugged 4-port RS-232 USB to Serial Converter - Wide Temperature is the smart solution for connecting professional grade RS-232 serial devices such as modems, ISDN terminal adapters, PDAs, bar code scanners, label printers, and more. It is compliant with USB specification, revision 2.0, comes with FCC and CE regulatory approvals, and meets RoHS hazardous materials standards. Additionally, it is compatible with a wide variety of Windows operating systems and backed by SIIG's limited 5-year warranty.

Model
Brand	SIIG
Model	ID-SC0G11-S1

Details
Changer Type	USB to Serial
Specifications	Compliant with USB Specification, Revision 2.0 Interfaces/Ports 1 x DB62 Female 1 x 4-Pin, USB, Type B, Input, Female Baud Rate: 300 to 921.6Kbps Input power: USB bus power (self power) or Dual DC inputs by 12-48VDC on 2-pin terminal block and power jack Power consumption: 2 Watts (400mA@5V USB Bus Power) 15KV ESD protection Dimension: 1.03" (W) x 3.74" (D) x 5.68" (H) Weight: 0.79 lbs Enclosure: IP-30 Storage Temperature: 40 to 85 degrees C (-40 to 185 degrees F) Operating temperature: -40 to 70 degrees C (-40 to 158 degrees F) Operating humidity: 5% to 95% RH Certificates/Standards: FCC, CE, RoHS

Features
Features	Compliant with USB 2.0 specification and backward compatible with USB 1.1 Supports RS-232 with RTS/CTS and DSR/DTR handshake signals Supports serial port data transfer rate up to 921.6Kbps USB bus powered, low power consumption Operating temperature range: -40 C to 70 degrees C Build-in 15KV ESD protection Equipped with DIN-Rail and panel mounting

Package Contents
Package Contents	CyberX Industrial Rugged 4-port RS-232 USB to Serial Converter - Wide Temperature USB cable (A to B) Power adapter Wall-mounting kit Round screws (M3x3, 8pcs) 2-Pin terminal block DB62 to 4xDB9 console cable Driver CD User's manual

Additional Information
Date First Available	January 08, 2013
