StarTech.com 2 Port 12V 1 Port 24V Dual Profile PCI Powered USB Card Model PCI1224PUSB
- PCI Powered USB Card
- 480/12/1.5 Mbps Data Transfer Rate
Specs
Reviews
Any questions? Our AI beta will help you find out quickly.
Try me now
Learn more about the STARTECH PCI1224PUSB
| Brand | StarTech.com |
|---|---|
| Model | PCI1224PUSB |
| Type | PCI Powered USB Card |
|---|---|
| External Ports | 2 x 8 pin USB PlusPower (12 V) Female 1 x 8 pin USB PlusPower (24 V) Female |
| Internal Ports | 1 x 9 pin IDC (Motherboard Header) Male 1 x 4 pin Power (LP4) Male |
| Data Transfer Rate | 480/12/1.5 Mbps |
| Operating Systems Supported | Windows 2000/ME/2003/XP/Vista |
| Features | 2 external 12V and 1 external 24V Powered USB Connectors SATA Power to LP4 adapter included Supports 32-bit PCI Bus Systems, PCI 2.2 Compliant USB2.0 EHCI, and USB1.1 OHCI Compliant Dual profile design for greatest compatibility Powered from either the PCI slot or the Power Supply of the PC with a standard LP4 connection Supplies power and data signals over hot-pluggable USB cable Can be linked to a daughter board or stand alone Selectable power input Backwards compatible with USB 2.0, 1.1 and 1.0 standards and allow for hot-plugging No external power is required Cable locking mechanism 9 pin internal USB connection can be used to expanded to the daughter board by connecting the USB header on the Main Board to the USB header on the daughter board using a USB cable |
|---|
| First Listed on Newegg | December 03, 2009 |
|---|
