16-Port USB-to-Serial Adapter Hub Convert a USB port into 16 RS232 serial ports in an industrial rack-mountable chassis - and daisy chain multiple hubs for a scalable solution.
Learn more about the STARTECH ICUSB23216FD
Model
Brand
StarTech.com
Model
ICUSB23216FD
Details
Type
USB-to-Serial Adapter Hub
Color
Black
Cable Length
No
Changer Type
USB to DB9 (RS-232)
Specifications
Bus Type: USB 2.0
Chipset ID: FTDI - FT232RL
Interface : Serial
Port Style: External Hub
Ports: 16
Data Bits: 7, 8
FIFO: 256 Bytes
Max Baud Rate: 921.6 Kbps
Maximum Data Transfer Rate: 480 Mbps
Parity: Odd, Even, Mark, Space, None
Serial Protocol: RS-232
Stop Bits: 1, 2
LED Indicators 16 - Data Receive 16 - Data Transmit
Center Tip Polarity: Positive
Input Current: 1.5 A
Input Voltage: 100 ~ 240 AC
Output Current: 3 A
Output Voltage: 12 DC
Plug Type: N
Power Consumption: 36 W Max.
Power Source: AC Adapter Included
Humidity: 20~80% RH (Non-condensing)
Operating Temperature: -40°C to 85°C (-40°F to 185°F)
Storage Temperature: -65°C to 150°C (-85°F to 302°F)
Enclosure Type: Steel
Connectors
Connector A
1x USB 2.0 Type B female
Connector B
16x DB-9 male
Features
Features
Convert a USB port into 16 RS232 serial ports in an industrial rack-mountable chassis and daisy chain multiple hubs for a scalable solution - 16-Port USB-to-Serial Adapter Hub - USB to RS232 port adapter with FTDI chipset and COM port retention - Rackmountable all-metal chassis - RS232 multiplexer with 921.6 Kbps baud per port - Meets the demands of industrial environments with extended operating temperature range: -40°C to 85°C (-40°F to 185°F)
Dimensions & Weight
Dimensions
1.80" x 4.70" x 16.90"
Weight
53.70 oz.
Package Contents
Package Contents
1 - 16-port USB to RS232 hub 1 - USB cable 2 - rack mounting brackets 8 - rack mounting screws 2 - DIN rail mounting brackets 4 - DIN rail mounting screws 4 - washers 4 - nuts 1 - universal power adapter (NA/EU/UK/AU) 1 - driver CD 1 - quick-start guide
