SUPERMICRO CSE-826BE1C4-R1K23LPB 2U Rackmount 2U Storage Chassis with 12x 3.5" hot-swap HDD's Redundant 1200W Titanium (96%+) efficiency power supplies w/ PMBus1.2 support

2U chassis support max. motherboard size - ATX 12" x 10", E-ATX 12" x 13", EE-ATX 13" x 13.68".
Support up to ATX 12"x13" MB with rear 2.5" HDD option installed
12 x 3.5" hot-swap SAS/SATA drive bay with SES3, optional 2 x 2.5" hot-swap drive bay
12-Port 2U Backplane with Expander support up to 8 x 3.5" SAS3/SATA3 HDD/SDD and 4 x SAS3/SATA3/NVMe Storage Devices,HF,RoHS/REACH
1U 1200W/1000W Titanium Power Supply W/PMbus W76xL336xH40mm
7 low-profile expansion slot(s)
3 x 8cm high-performance PWM fan(s)

Specs

Reviews

Any questions? Our AI beta will help you find out quickly.

Try me now

Learn more about the Supermicro CSE-826BE1C4-R1K23LPB

Model
Brand	SUPERMICRO
Model	CSE-826BE1C4-R1K23LPB

Details
Chassis Type	Rackmount
Form Factor	2U
Motherboard Compatibility	Support motherboard up to 12" x 13", ATX, E-ATX
Power Supply	Redundant 1200W Titanium (96%+) efficiency power supplies w/ PMBus1.2 support

Features
Features	4x Hot-swap 2.5" NVMe supported NVMe/SAS3 Hybrid Drive Bays provide Ultimate Flexibility / Upgradability 12Gbps 12-bay Expander and Direct Attach backplane boards Redundant 1200W Titanium Level PWS Rear dual 2.5" HDD support (12" x 13' MB only) Default support 205W X11 Dual Processors

Dimensions & Weight
Dimensions	3.50" x 17.20" x 25.50"

Additional Information
First Listed on Newegg	April 11, 2018
