Supermicro SYS-6048R-E1CR36N - 36 Bay 3.5" 4U Server - 2x Intel Xeon E5-2667 v4 3.2GHz 8 Core Processors, 16GB DDR4, 9361-8i, 36x 3.5" Trays, X540, IPMI 2.0, 2x 1280 Watt PSUs,
REFURBISHED Product Type
- 2x Intel Xeon E5-2667 v4 3.2GHz (3.6GHz Turbo) 8 Core Processors.
- 16GB (2x 8GB) DDR4 2400MHz Registered ECC Memory.
- MegaRAID 9361-8i 8-Port SAS 12Gb/s PCIe Raid Controller 1GB Cache w/Battery.
- 36x Supermicro 3.5" SAS/SATA Hard Disk Drive Trays - No Hard Disk Drives.
- 4x 10GBase-T LAN with Intel X540 Ethernet Controller.
- IPMI 2.0 with virtual media over LAN and KVM-over-LAN support (1x RJ45 Dedicated IPMI LAN port).
- 2x Supermicro 1U 1280W 80 Plus Platinum Power Supplies.
- Front Bezel and Rack Mount Rails Not Included.
- No Operating System Installed.
- 30 Day Money Back Guarantee, 1 Year Parts and Labor Warranty.
+
+
Overview
Specs
Reviews
Supermicro SuperStorage SYS-6048R-E1CR36N 36-Bay 3.5" 4U Rackmount Server
Massive Storage Capacity Meets Enterprise-Class Performance
The Supermicro SYS-6048R-E1CR36N is engineered for high-density storage environments, offering exceptional scalability and performance. With support for up to 36 hot-swap 3.5" SAS3/SATA3 drives and dual Intel® Xeon® E5-2600 v4/v3 processors, it's ideal for enterprise storage, data archiving, and high-throughput applications.
Key Features:
Dual Intel® Xeon® E5-2600 v4/v3 CPUs Supports up to 22 cores per processor and 145W TDP, delivering robust processing power for demanding workloads.
24 DDR4 DIMM Slots Accommodates up to 3TB ECC 3DS LRDIMM or 1.5TB ECC RDIMM, ensuring ample memory capacity for intensive applications.
36 Hot-Swap 3.5" Drive Bays Configured with 24 front and 12 rear bays, supporting SAS3/SATA3 drives for extensive storage needs.
Broadcom SAS3 RAID Controller Integrated LSI 3108 hardware RAID controller offers RAID levels 0, 1, 5, 6, 10, 50, and 60 for data protection and performance optimization.
Quad 10GBase-T LAN Ports Intel® X540 Ethernet controller provides high-speed networking with support for 10GBASE-T, 100BASE-TX, and 1000BASE-T.
Redundant 1280W Platinum Power Supplies Ensures high efficiency and reliability with PMBus support for power management.
Advanced Cooling System Equipped with 7x 80mm middle cooling fans to maintain optimal operating temperatures.
Comprehensive Remote Management Features IPMI 2.0 with virtual media over LAN and KVM-over-LAN support via ASPEED AST2400 BMC.
Technical Specifications:
Motherboard: Super X10DRi-T4+
Chipset: Intel® C612
Memory Capacity: Up to 3TB ECC 3DS LRDIMM or 1.5TB ECC RDIMM
Memory Type: DDR4 2400/2133/1866/1600MHz ECC SDRAM
Expansion Slots: 2 PCI-E 3.0 x16, 3 PCI-E 3.0 x8, 1 PCI-E 2.0 x4 (in x8)
USB Ports: 3 USB 3.0 (2 rear, 1 Type A), 2 USB 2.0 (rear)
Video: 1 VGA port via ASPEED AST2400 BMC
Serial Ports: 1 Fast UART 16550 port, 1 header
Chassis: 4U Rackmount (CSE-847BE1C-R1K28LPB)
Dimensions (W x H x D): 17.2" x 7" x 27.5" (437mm x 178mm x 699mm)
Operating Temperature: 10°C to 35°C (50°F to 95°F)
Operating Relative Humidity: 8% to 90% (non-condensing)
Why Choose Supermicro?
Supermicro is renowned for delivering high-quality, energy-efficient servers with advanced features and robust support. The SYS-6048R-E1CR36N offers the perfect balance of performance, scalability, and reliability for demanding enterprise workloads.
Optimize your data center with the Supermicro SYS-6048R-E1CR36N engineered for high-performance computing and enterprise scalability.
Do you need assistance custom configuring a system for a certain use case scenario? No problem, we are here to help and can create a custom listing for you. Contact Us Today at (844) 338-0285
PLEASE NOTE - STOCK PHOTOS ARE SHOWN AND MAY NOT BE THE ACTUAL UNIT SHIPPED.
Massive Storage Capacity Meets Enterprise-Class Performance
The Supermicro SYS-6048R-E1CR36N is engineered for high-density storage environments, offering exceptional scalability and performance. With support for up to 36 hot-swap 3.5" SAS3/SATA3 drives and dual Intel® Xeon® E5-2600 v4/v3 processors, it's ideal for enterprise storage, data archiving, and high-throughput applications.
Key Features:
Dual Intel® Xeon® E5-2600 v4/v3 CPUs Supports up to 22 cores per processor and 145W TDP, delivering robust processing power for demanding workloads.
24 DDR4 DIMM Slots Accommodates up to 3TB ECC 3DS LRDIMM or 1.5TB ECC RDIMM, ensuring ample memory capacity for intensive applications.
36 Hot-Swap 3.5" Drive Bays Configured with 24 front and 12 rear bays, supporting SAS3/SATA3 drives for extensive storage needs.
Broadcom SAS3 RAID Controller Integrated LSI 3108 hardware RAID controller offers RAID levels 0, 1, 5, 6, 10, 50, and 60 for data protection and performance optimization.
Quad 10GBase-T LAN Ports Intel® X540 Ethernet controller provides high-speed networking with support for 10GBASE-T, 100BASE-TX, and 1000BASE-T.
Redundant 1280W Platinum Power Supplies Ensures high efficiency and reliability with PMBus support for power management.
Advanced Cooling System Equipped with 7x 80mm middle cooling fans to maintain optimal operating temperatures.
Comprehensive Remote Management Features IPMI 2.0 with virtual media over LAN and KVM-over-LAN support via ASPEED AST2400 BMC.
Technical Specifications:
Motherboard: Super X10DRi-T4+
Chipset: Intel® C612
Memory Capacity: Up to 3TB ECC 3DS LRDIMM or 1.5TB ECC RDIMM
Memory Type: DDR4 2400/2133/1866/1600MHz ECC SDRAM
Expansion Slots: 2 PCI-E 3.0 x16, 3 PCI-E 3.0 x8, 1 PCI-E 2.0 x4 (in x8)
USB Ports: 3 USB 3.0 (2 rear, 1 Type A), 2 USB 2.0 (rear)
Video: 1 VGA port via ASPEED AST2400 BMC
Serial Ports: 1 Fast UART 16550 port, 1 header
Chassis: 4U Rackmount (CSE-847BE1C-R1K28LPB)
Dimensions (W x H x D): 17.2" x 7" x 27.5" (437mm x 178mm x 699mm)
Operating Temperature: 10°C to 35°C (50°F to 95°F)
Operating Relative Humidity: 8% to 90% (non-condensing)
Why Choose Supermicro?
Supermicro is renowned for delivering high-quality, energy-efficient servers with advanced features and robust support. The SYS-6048R-E1CR36N offers the perfect balance of performance, scalability, and reliability for demanding enterprise workloads.
Optimize your data center with the Supermicro SYS-6048R-E1CR36N engineered for high-performance computing and enterprise scalability.
Do you need assistance custom configuring a system for a certain use case scenario? No problem, we are here to help and can create a custom listing for you. Contact Us Today at (844) 338-0285
PLEASE NOTE - STOCK PHOTOS ARE SHOWN AND MAY NOT BE THE ACTUAL UNIT SHIPPED.
