Supermicro 1U Gold Series Edge Server (SYS-110P-FRN2T-02-G1)

Be the first to review this product...
  • Single Intel Xeon 4310 (12C/2.1GHz)
  • 64GB DDR4-3200
  • 1x 480GB 2.5" SATA
  • 1x 480GB M.2 NVMe SSD
  • Onboard dual 10GbE RJ45
  • 1x 800W Platinum Level
Please note that this product is non-returnable and non-refundable.
+
+
Specs
Reviews
avatar

Any questions? Our AI beta will help you find out quickly.

Try me now

Learn more about the Supermicro SYS-110P-FRN2T-02-G1

Model
Brand SUPERMICRO
Series Gold Series
Model SYS-110P-FRN2T-02-G1
Details
Workload Edge Server
Type Rack
Rack Height 1U
LEDs Fan Fail/System Over Heat LED
HDD activity LED
Network Activity LEDs
Power status LED
Hot-swap Fans 5 heavy duty fans with optimal fan speed control
Processor
CPU Type Intel Xeon Silver
CPU Speed 4310 (2.10 GHz)
Number of CPU Cores 12-Core Processor
Cache Memory 18 MB
# of Processors Installed 1
MAX Processors 1
Memory
Installed Memory Size 64GB
Memory Type DDR4 3200
Memory Features Max Memory (2DPC): Up to 2TB 3200MT/s ECC DDR4 RDIMM/LRDIMM
Number of Memory Slots 8
Storage
Storage Controller 1 x AOM-TPM-9670V-P - Trusted Platform Module (TPM) 2.0
SSD (Installed) 1 x 480GB M.2 7450 PRO NVMe PCIe 4.0 Solid State Drive
1 x 480GB 2.5" PM893 SATA 6Gb/s Solid State Drive (1 x DWPD)
Networking
Ethernet Controller 1 x 2 10GbE RJ45 Ports
Expansion & Ports
Expansion Bays 2 internal fixed 2.5" SATA drive bays
1 M.2 PCIe 3.0 x4 NVMe/SATA slot (M-key 2280/22110)
Power
Power Characteristics 1 x 800W Platinum Level
Environmental
Temperature Operating Temperature: 0°C to 40°C (32°F to 104°F)
Non-operating Temperature: -40°C to 70°C (-40°F to 158°F)
Humidity Operating Relative Humidity: 8% to 90% (Non-Condensing)
Non-operating Relative Humidity: 5% to 95% (Non-Condensing)
Dimensions & Weight
Dimensions 1.7" x 17.2" x 15.7"
Weight 18 lbs.
Additional Information
First Listed on Newegg July 29, 2025

Warranty & Returns

Warranty, Returns, And Additional Information

Warranty

  • Limited Warranty period (parts): 1 year
  • Limited Warranty period (labor): 1 year
