Supermicro 1U Gold Series Edge Server (SYS-510D-4C-FN6P-02-G1)
- Single Intel Xeon D-1718T (4C/2.6GHz)
- 16GB DDR4-3200
- 1x 960GB M.2 NVMe SSD
- 4 GbE and dual 25G SFP28
- 1x 200W Gold Level
+
+
Learn more about the Supermicro SYS-510D-4C-FN6P-02-G1
| Brand | SUPERMICRO |
|---|---|
| Series | Gold Series |
| Model | SYS-510D-4C-FN6P-02-G1 |
| Workload | Edge Server |
|---|---|
| Type | Rack |
| Rack Height | Mini-1U |
| LEDs | Fan Fail/System Over Heat LED HDD activity LED Network Activity LEDs Power status LED |
| Hot-swap Fans | 4x 4-PIN PWM 40x28mm Fan(s) (optional) |
| CPU Type | Intel Xeon D |
|---|---|
| CPU Speed | D-1718T (2.60 GHz) |
| Number of CPU Cores | Quad-Core Processor |
| Cache Memory | 10 MB |
| # of Processors Installed | 1 |
| MAX Processors | 1 |
| Installed Memory Size | 16GB |
|---|---|
| Memory Type | DDR4 3200 |
| Memory Features | Max Memory (2DPC): Up to 256GB 2933MT/s ECC DDR4 RDIMM |
| Number of Memory Slots | 4 |
| SSD (Installed) | 1 x 960GB M.2 7450 PRO NVMe (80mm) PCIe 4.0 Solid State Drive |
|---|
| Ethernet Controller | 1 x 2 25GbE SFP28 Ports + 2 1GbE RJ45 Ports + 2 1GbE RJ45 Ports |
|---|
| Expansion Bays | 4 internal fixed 2.5" SATA drive bays 1 M.2 PCIe 3.0 x1 SATA slot (E-key 2230; USB 2.0) 1 M.2 PCIe 3.0 x2 SATA slot (B-key 2280/3042/3052; USB 3.0) 1 M.2 PCIe 3.0 x4 SATA slot (M-key 2280) |
|---|
| Power Characteristics | 1 x 200W Gold Level |
|---|
| Temperature | Operating Temperature: 0°C to 40°C (32°F to 104°F) Non-operating Temperature: -40°C to 70°C (-40°F to 158°F) |
|---|---|
| Humidity | Operating Relative Humidity: 8% to 90% (Non-Condensing) Non-operating Relative Humidity: 5% to 95% (Non-Condensing) |
| Dimensions | 1.7" x 17.2" x 9.8" |
|---|---|
| Weight | 10 lbs. |
| First Listed on Newegg | August 04, 2025 |
|---|
