Supermicro 1U Hyper SuperServer (SYS-121H-TNR-02-G1)

Be the first to review this product...
  • Dual Intel Xeon 6542Y (24C/2.9GHz)
  • 256GB DDR5-5600
  • 1x 3.8TB U.2 NVMe SSD
  • 1 dual 10GbE RJ45
  • 2x 1200W Titanium Level
Please note that this product is non-returnable and non-refundable.
+
+
Specs
Reviews

Learn more about the Supermicro SYS-121H-TNR-02-G1

Model
Brand SUPERMICRO
Series SuperServer
Model SYS-121H-TNR-02-G1
Details
Workload General Purpose Server
Type Rack
Rack Height 1U
LEDs HDD activity
LAN1 activity
Power
System information
Hot-swap Fans 8 counter-rotating 40x40x56mm Fan(s)
Security Trusted Platform Module (TPM) 2.0
Silicon Root of Trust (RoT) - NIST 800-193 Compliant
Cryptographically Signed Firmware
Secure Boot
Secure Firmware Updates
Automatic Firmware Recovery
Supply Chain Security: Remote Attestation
Runtime BMC Protections
System Lockdown
Processor
CPU Type Intel Xeon Gold
CPU Speed 6542Y (2.90 GHz)
Number of CPU Cores 24-Core Processor
Cache Memory 60 MB L3 Cache
# of Processors Installed 1
MAX Processors 1
Memory
Installed Memory Size 256GB
Memory Type DDR5
Max Memory Capacity 8TB
Memory Features Max Memory (1DPC): Up to 4TB 5600MT/s ECC DDR5 RDIMM
Max Memory (2DPC): Up to 8TB 4400MT/s ECC DDR5 RDIMM
Number of Memory Slots 32
Storage
Hard Drive (Installed) None
SSD (Installed) 3.84TB
Raid Level RAID 0/1/5/10
Expansion & Ports
Expansion Slots 1 PCIe 5.0 x16 FHHL slot
2 PCIe 5.0 x16 FH/10.5"L slots
1 PCIe 5.0 x16 AIOM slot (OCP 3.0 compatible)
Expansion Bays 8 front hot-swap 2.5" NVMe*/SAS*/SATA* drive bays
2 M.2 NVMe/SATA slots (B+M-key 2280/22110)
Power
Power Characteristics 2 x 1200W Redundant Titanium Level (96%) Hot-plug power supplies
Environmental
Temperature Operating Temperature: 10°C to 35°C (50°F to 95°F)
Non-operating Temperature: -30°C to 60°C (-40°F to 140°F)
Humidity Operating Relative Humidity: 8% to 80% (max 21° DP; non-condensing)
Non-operating Relative Humidity: 8% to 90% (max 38° DP; non-condensing)
Dimensions & Weight
Dimensions 1.7" x 17.2" x 29.4"
Weight 34 lbs.
