SUPERMICRO SYS-1016T-M3FB 1U Barebone Server Intel X58 LGA 1366 Intel Xeon 5600/5500 Series

(1) Write a Review
  • LGA 1366
  • Intel Xeon
  • 6 x 240Pin Memory Slots
  • 560W 85%+ High-efficiency Power Supply, 80PLUS Silver
Specs
Reviews (1)
avatar

Any questions? Our AI beta will help you find out quickly.

Try me now

Learn more about the Supermicro SYS-1016T-M3FB

General
Brand SUPERMICRO
Model SYS-1016T-M3FB
Form Factor 1U Rackmount
CPU Supported
CPU Type Intel Xeon
CPU Socket LGA 1366
Chipset
North Bridge Intel X58
South Bridge ICH10R
Memory Supported
Memory Slots 6 x 240Pin
Max Memory Supported 24GB
Memory Type Supported DDR3 1333/1066/800
Channel Supported Triple Channel
ECC Supported Yes
Storage Supported
Serial ATA 6 x SATA 300
SATA RAID RAID 0/1/5/10
SAS 8 SAS / SATA ports

LSI SAS1068E
RAID 0, 1, 10 support
Graphics
GPU/VPU Integrated Video
Expansion Slots
PCI Express 1 (x16) PCI-e 2.0 slot
1 (x8) PCI-e slot
PCI 1
Communications
First LAN Intel 82574L
Second LAN Intel 82574L
Max. LAN Speed Dual 1 Gigabit
Expansion Bays
Hot-Swap Bays 8 x 2.5"
Panel Ports
COM 1
PS/2 2
VGA 1
Rear USB 2
RJ45 2
Power Supply
Max. Power 560W 85%+ High-efficiency Power Supply, 80PLUS Silver
Features
Features Integrated IPMI2.0 with Dedicated LAN

1x SAS / SATA Backplane

CPU:
Intel Xeon Processor 5600 Series (Westmere)
Intel Xeon Processor 5500 Series (Nehalem-EP)
NOTE: Intel Xeon 3500 Series and Core i7 are Not Supported (Max TDP > 100 Watts)
Dimensions & Weight
Dimensions 20" x 17.2" x 1.7"
Weight 18.5 lbs.
Additional Information
First Listed on Newegg March 02, 2009

Warranty & Returns

Warranty, Returns, And Additional Information

Warranty

  • Limited Warranty period (parts): 1 year
  • Limited Warranty period (labor): 3 years
