SUPERMICRO SYS-2027PR-HC1FR 2U Rackmount Server Barebone Dual LGA 2011 Intel C606 DDR3 1866/1600/1333/1066/800
- Dual LGA 2011
- Support Dual Intel Xeon E5-2600 and E5-2600 v2 family (up to 135W TDP)
- 16 x 240Pin Memory Slots
- Support 6 x SAS 3 HDD
- 2000W Redundant Power Supplies with IC & PMBus
+
+
Specs
Reviews
Any questions? Our AI beta will help you find out quickly.
Try me now
Learn more about the Supermicro SYS-2027PR-HC1FR
| Brand | SUPERMICRO |
|---|---|
| Model | SYS-2027PR-HC1FR |
| Form Factor | 2U Rackmount |
| CPU Type | Support Dual Intel Xeon E5-2600 and E5-2600 v2 family (up to 135W TDP) |
|---|---|
| CPU Socket | Dual LGA 2011 |
| Installed CPU | No CPU Installed |
| Max Processors | 2 |
| North Bridge | Intel C606 |
|---|
| Memory Slots | 16 x 240Pin |
|---|---|
| Installed Memory Size | No Memory Installed |
| Max Memory Supported | Up to 1TB DDR3 ECC LRDIMM Up to 512GB DDR3 ECC Registered memory (RDIMM) |
| Memory Type Supported | DDR3 1866/1600/1333/1066/800 |
| ECC Supported | Yes |
| Registered | Yes |
| Installed HDD | No Storage Installed |
|---|---|
| SAS | 6x SAS3 (12Gbps) ports LSI 3108 SAS3 (12Gbps) controller; RAID 0, 1, 5, 6, 10, 50 support |
| GPU/VPU | Matrox G200eW |
|---|
| PCI Express | 1x PCI-E 3.0 x16 Low-profile slot |
|---|
| First LAN | Intel I350 |
|---|---|
| Max. LAN Speed | Dual 1 Gigabit |
| Hot-Swap Bays | 6x 2.5" Hot-swap SAS/SATA HDD trays |
|---|
| COM | 1x Fast UART 16550 port / 1 Header |
|---|---|
| VGA | 1 |
| Rear USB | 2 |
| RJ45 | 2x RJ45 Gigabit Ethernet LAN ports 1x RJ45 Dedicated IPMI LAN port |
| Other Ports | 1 external QSFP Infiniband connector |
| Max. Power | 2000W Redundant Power Supplies with IC & PMBus |
|---|
| Features | IPMI Support for Intelligent Platform Management Interface v.2.0 IPMI 2.0 with virtual media over LAN and KVM-over-LAN support Nuvoton WPCM450 BMC Front Panel Buttons Power On/Off button System Reset button UID button LEDs Power status LED HDD activity LED 2x Network activity LEDs Universal Information (UID) LED Infiniband Mellanox ConnectX-3 FDR Infiniband 56Gb/s Controller 4x 8cm heavy duty PWM fans with optimal fan speed control |
|---|
| Dimensions | 3.47" x 17.25" x 28.5" (H x W x D) |
|---|---|
| Weight | Gross: 85lbs |
| First Listed on Newegg | January 06, 2016 |
|---|
