SUPERMICRO SYS-5015B-MTB 1U Rackmount Server Barebone, LGA 775 Intel Xeon 1333/1066/800MHz
- LGA 775
- Intel Xeon
- Intel 3210 1333/1066/800MHz FSB
- 4 x 240Pin Memory Slots
Specs
Reviews (8)
Any questions? Our AI beta will help you find out quickly.
Try me now
Learn more about the Supermicro SYS-5015B-MTB
| Brand | SUPERMICRO |
|---|---|
| Model | SYS-5015B-MTB |
| Form Factor | 1U Rackmount |
| CPU Type | Intel Xeon |
|---|---|
| CPU Socket | LGA775 ZIF |
| FSB | 1333/1066/800MHz |
| North Bridge | Intel 3210 |
|---|---|
| South Bridge | ICH9R |
| Memory Slots | 4 x 240Pin |
|---|---|
| Max Memory Supported | 8GB |
| Memory Type Supported | DDR2 800/667 |
| Channel Supported | Dual Channel |
| ECC Supported | Yes |
| ATA | 1x ATA 33/66/100 |
|---|---|
| Serial ATA | 6 x SATA 300 |
| SATA RAID | RAID 0, 1, 5, 10 support (Windows Only) RAID 0, 1, 10 support (Linux) |
| GPU/VPU | ATI ES1000 |
|---|---|
| Video Memory | 32MB |
| PCI Express | 1 x Universal (x8) PCI-e slot (OR) |
|---|---|
| PCI-X | 1x 133 MHz |
| First LAN | Intel 82573V |
|---|---|
| Second LAN | Intel 82573L |
| Max. LAN Speed | 1 Gigabit |
| Hot-Swap Bays | 4x 3.5" SATA |
|---|
| Front USB | 2 |
|---|---|
| COM | 1 |
| PS/2 | 2 |
| VGA | 1 |
| Rear USB | 2 |
| RJ45 | 2 |
| Other Ports | 1 x Serial COM Port (Front) |
| Max. Power | Fixed 300W AC power supply module with PFC |
|---|
| Features | Color: Black Processor: Supports Quad-Core Intel Xeon X3300/X3200 series. Supports Dual-Core Intel Xeon E3100/3000 series. Supports Intel Xeon processor L3360 and L3110 series. Supports Intel Core2 Quad Q9000/Q8000/Q6000 series. Supports Intel Core2 Duo E8000/E7000/E6000/E4000 series. Supports Intel Pentium E5000/E2000 series. Supports Intel Celeron E1000 and 400 series. NOTE: Intel Xeon processor L3014 requires an LGA771 socket and is not supported. Super I/O: Winbond 83627DHG chip Serial ATA: Four SATA hard drives supported External SATA supported Buttons: Power On/Off button, System Reset button LEDs: Power LED Hard drive activity LED 2x Network activity LEDs System Overheat / Fan Fail LED System Fans: 3 x Cooling Fans. Other: Chassis intrusion detection, Chassis intrusion header. |
|---|
| Dimensions | 19.8" x 17.2" x 1.7" |
|---|---|
| Weight | 38.0 lbs. |
| First Listed on Newegg | January 24, 2008 |
|---|
