Brand | SUPERMICRO |
---|---|
Model | SYS-5019C-FL |
CPU Type | Single Socket H4 (LGA 1151), CPU TDP support up to 95W Support Intel Xeon Processor E-2100 series, 8th Gen. Intel Core i3 / Pentium / Celeron Processors |
---|---|
CPU Socket | LGA 1151 |
North Bridge | Intel C242 |
---|
Max Memory Supported | 2 x DIMM slots Up to 64GB Unbuffered ECC UDIMM Up to DDR4-2666 MHz |
---|---|
Memory Type Supported | DDR4 2666 / 2400 / 2133 MHz ECC SDRAM |
ECC Supported | Yes |
Serial ATA | 4 x SATA 600 |
---|---|
SATA RAID | RAID 0/1/5/10 |
GPU/VPU | Aspeed AST2500 BMC |
---|
PCI Express | 1 x PCI-E 3.0 x16 slot, for low-profile AOC |
---|
Number of LAN | Dual LAN with Intel I210-AT |
---|---|
First LAN | Intel I210-AT |
Second LAN | Intel I210-AT |
RJ45 | 2 x RJ45 Gigabit Ethernet LAN ports 1 x RJ45 Dedicated IPMI LAN port |
---|
Features | Single socket H4 (LGA 1151) supports Intel Xeon processor E-2100, 8th Gen. Intel Core i3 Processors, Intel Celeron, Intel Pentium Intel C242 chipset Up to 64GB ECC UDIMM, up to DDR4-a2666 MHz; 2 x DIMM slots 1 x PCI-E 3.0 x16 slot 2 x Fixed 3.5" drive bay or 4 x Fixed 2.5" drive bays M.2 Interface: 1 x PCI-E 3.0 x4 M.2 Form Factor: 2280 M.2 Key: M-Key 2 x GbE LAN ports, 1 x dedicated IPMI LAN 2 x USB 3.1 (rear), 2 x USB 2.0 (rear) 1 x VGA, 2 x COM, 1 x TPM 200W Multi-output power supply, Gold Level Certified |
---|
Form Factor | 1U Rackmount |
---|
Dimensions | 1.70" x 17.20" x 9.80" |
---|
Date First Available | July 05, 2023 |
---|
