SUPERMICRO SYS-5037MR-H8TRF 3U Rackmount Server Barebone (8 Nodes) LGA 2011 Intel C602J DDR3 1866/1600/1333/1066

Be the first to review this product...
  • 1 x LGA 2011
  • Support Intel Xeon E5-2600 and E5-2600 v2 series (Up to 130W)
  • 4 x 240Pin Memory Slots (Max 128GB)
  • Support 2 x SATA 600 HDD
  • 1620W high-efficiency redundant power supply
Specs
Reviews
avatar

Any questions? Our AI beta will help you find out quickly.

Try me now

Learn more about the Supermicro SYS-5037MR-H8TRF

General
Brand SUPERMICRO
Series SuperServer
Model SYS-5037MR-H8TRF
Form Factor 3U Rackmount
CPU Supported
CPU Type Intel Xeon E5-2600 and E5-2600 v2 series (Up to 130W)
CPU Socket LGA 2011
Installed CPU No CPU Installed
Max Processors 1
Chipset
North Bridge Intel C602J
Memory Supported
Memory Slots 4 x 240Pin
Installed Memory Size No Memory Installed
Max Memory Supported 128GB RDIMM
Memory Type Supported DDR3 1866/1600/1333/1066
ECC Supported Yes
Registered Yes
Storage Supported
Installed HDD No Storage Installed
Serial ATA 2 x SATA 600
SATA RAID RAID 0/1/5/10
Graphics
GPU/VPU Matrox G200eW
Video Memory 16MB
Expansion Slots
PCI Express 1 (x8) PCI-E 3.0 Low-profile slot
Communications
First LAN Intel I350
Max. LAN Speed Dual 1 Gigabit
Expansion Bays
Hot-Swap Bays 2 x 3.5" (per node)
Panel Ports
COM 1
VGA 1
Rear USB 2 x USB 2.0
RJ45 2x RJ45 Gigabit Ethernet LAN ports
1x RJ45 Dedicated IPMI LAN port
Power Supply
Max. Power 1620W high-efficiency redundant power supply w/ PMBus, 80 PLUS Platinum
Features
Features 8 Nodes

Drive Bays:
2x 3.5" hot-swap SATA3 (6Gbps) HDDs per node; up to 16 HDDs total
Enterprise SATA HDD only recommended

Fans: 4x 8cm 11K RPM, 4-pin PWM cooling fans
Dimensions & Weight
Dimensions 5.21" x 17.26" x 23.2" (H x W x D)
Weight 62.2lbs
Additional Information
First Listed on Newegg October 07, 2013
