SuperServer 5039MS-H8TRF
The SuperServer 5039MS-H8TRF from Supermicro is a single-socket barebone, great for small to midsize businesses seeking performance, reliability and expandability. Based on Intel C236 chipset, this tower server supports diverse Intel processors, and features 4 DDR4 DIMM slots to accommodate staggering amount of memory. It delivers substantial compute power to handle Cloud, virtualization, database processing and other compute-intensive applications. The redundant power supply design helps reduce downtime, while the 80 Plus Titanium certification means less energy waste and lower electricity bill.
SpecificationsMfr Part Number: SYS-5039MS-H8TRFMotherboard: MBD-X11SSD-FProcessor Per Node: LGA1151Supports Intel Xeon E3-1200 v5 Series ProcessorsUp to 80W TDPChipset Per Node: Intel C236Memory Per Node: 4x 288pin DDR4-2133 DIMM Slots, ECC, Unbuffered, Max Capacity of 64GBSlots Per Node: 1x PCI-Express 3.0 x8 Slot (Low-profile); 1x Micro-LP for Dual GbE (pre-installed)SATA Per Node: 2x SATA3 PortsVideo Per Node: Aspeed AST2400 BMC GraphicsLAN Per Node: 2x Intel i350 Gigabit Ethernet ControllersDrive Bays Per Node: 2x 3.5" Hot-swap SATA3 HDDs; up to 16 HDDs totalPorts per Node: 1x USB 3.0 Type A Port, 2x USB 2.0 Ports, 1x VGA Port, 2x RJ45 LAN Ports, 1x RJ45 Dedicated IPMI LAN PortForm Factor: 3U RackmountPower Supply: 1600W 80 PLUS Titanium Certified High-efficiency Redundant Single Output Power SuppliesSystem Cooling: 4x 8cm Heavy duty fans w/ optimal cooling zoneFront Panel:Buttons: Power On/OffLEDs: Power, Node StatusColor: BlackDimensions (WxDxH): 17.26 x 23.20 x 5.2
