SUPERMICRO SYS-6017R-TDF+ 1U Rackmount Server Barebone Dual LGA 2011 Intel C602J DDR3 1600/1333/1066/800

Be the first to review this product...
  • Dual LGA 2011
  • Dual Intel Xeon E5-2600 (Up to 115W)
  • 16 x 240Pin Memory Slots
  • 600W High-efficiency power supply, 80PLUS Gold
Specs
Reviews
avatar

Any questions? Our AI beta will help you find out quickly.

Try me now

Learn more about the Supermicro SYS-6017R-TDF+

General
Brand SUPERMICRO
Series SuperServer
Model SYS-6017R-TDF+
Form Factor 1U Rackmount
CPU Supported
CPU Type Dual Intel Xeon E5-2600 (Up to 115W)
CPU Socket Dual LGA 2011
Chipset
North Bridge Intel C602J
Memory Supported
Memory Slots 16 x 240Pin
Max Memory Supported 512GB RDIMM
Memory Type Supported DDR3 1600/1333/1066/800
ECC Supported Yes
Registered Yes
Storage Supported
Serial ATA 2 x SATA 300 + 2 SATA 600
SATA RAID RAID 0/1/5/10
Graphics
GPU/VPU Matrox G200eW
Expansion Slots
PCI Express 1x PCI-E 3.0 x8 Full-height, Full-length
Communications
First LAN Intel I350
Max. LAN Speed Dual 1 Gigabit
Expansion Bays
Hot-Swap Bays 4 x 3.5" SATA
Panel Ports
COM 1
VGA 1
Rear USB 4
RJ45 2x RJ45 Gigabit Ethernet LAN ports
1x RJ45 Dedicated IPMI LAN port
Other Ports USB 2.0: 4x via header + 1x Type A
Power Supply
Max. Power 600W High-efficiency power supply, 80PLUS Gold
Features
Features IPMI 2.0 with virtual media over LAN and KVM-over-LAN support

1x 1U SAS / SATA backplane
Dimensions & Weight
Dimensions 25.6" x 17.2" x 1.7"
