SUPERMICRO SYS-6027TR-D71RF 2U Rackmount Server Barebone Dual LGA 2011 Intel C602 DDR3 1866/1600/1333/1066/800
- Dual LGA 2011
- Support Dual Intel Xeon E5-2600 and E5-2600 v2 family (up to 135W TDP)
- 8 x 240Pin Memory Slots (Max 512GB)
- 1280W Redundant High-efficiency Digital Power Supplies w/ PMBus 1.2
Specs
Reviews
Any questions? Our AI beta will help you find out quickly.
Try me now
Learn more about the Supermicro SYS-6027TR-D71RF
| Brand | SUPERMICRO |
|---|---|
| Model | SYS-6027TR-D71RF |
| Form Factor | 2U Rackmount |
| CPU Type | Support Dual Intel Xeon E5-2600 and E5-2600 v2 family (up to 135W TDP) |
|---|---|
| CPU Socket | Dual LGA 2011 |
| Installed CPU | No CPU Installed |
| Max Processors | 2 |
| North Bridge | Intel C602 |
|---|
| Memory Slots | 8 x 240Pin |
|---|---|
| Installed Memory Size | No Memory Installed |
| Max Memory Supported | Up to 512GB DDR3 ECC LRDIMM Up to 256GB DDR3 ECC Registered memory (RDIMM) |
| Memory Type Supported | DDR3 1866/1600/1333/1066/800 |
| ECC Supported | Yes |
| Registered | Yes |
| Installed HDD | No Storage Installed |
|---|---|
| Serial ATA | 2 x SATA 600 + 5 x SATA 300 |
| SATA RAID | RAID 0/1/5/10 |
| SAS | 8x SAS2 ports (6Gbps) LSI 2108 SAS (6Gbps) w/ Hardware RAID support RAID 0, 1, 5, 6, 10, 50, 60 support |
| GPU/VPU | Matrox G200eW |
|---|
| PCI Express | 3x PCI-E 3.0 (x8) slots (1x Low-profile and 2x Full-height Full-length) |
|---|
| First LAN | Intel I350 |
|---|---|
| Max. LAN Speed | Dual 1 Gigabit |
| Hot-Swap Bays | 6x Hot-swap 3.5" SATA3/SAS2 HDD trays |
|---|
| COM | 1x Fast UART 16550 port / 1 Header |
|---|---|
| VGA | 1 |
| Rear USB | 2 |
| RJ45 | 2x RJ45 Gigabit Ethernet LAN ports 1x RJ45 Dedicated IPMI LAN port |
| Max. Power | 1280W Redundant High-efficiency Digital Power Supplies w/ PMBus 1.2 |
|---|
| Features | IPMI Support for Intelligent Platform Management Interface v.2.0 IPMI 2.0 with virtual media over LAN and KVM-over-LAN support Nuvoton WPCM450 BMC Front Panel Buttons Power On/Off button System Reset button UID button LEDs Power status LED HDD activity LED 2x Network activity LEDs Universal Information (UID) LED 4x 8cm heavy duty PWM fans with optimal fan speed control |
|---|
| Dimensions | 3.47" x 17.25" x 28.5" (H x W x D) |
|---|---|
| Weight | Gross: 85lbs |
| First Listed on Newegg | April 23, 2014 |
|---|
