SUPERMICRO SYS-6028R-TT 2U Rackmount Server Barebone Dual LGA 2011 Intel C612 DDR4 2133/1866/1600

Be the first to review this product...

Dual LGA 2011
Intel Xeon processor E5-2600 v3 family (up to 145W TDP)
16 x 288Pin Memory Slots
650W

Overview

Specs

Reviews

Any questions? Our AI beta will help you find out quickly.

Try me now

Supermicro's New Generation X10 Haswell DP SuperServer® offers numerous advantages over previous generations including the highest levels of performance, efficiency, security and scalability in the industry.

SANUS LF228-B1 HDPro 28" Full Motion Mount for 37"-65" TVs, black

Model
Brand	SUPERMICRO
Model	SYS-6028R-TT

CPU Supported
CPU Type	Intel Xeon processor E5-2600 v3 family (up to 145W TDP)
CPU Socket	Dual LGA 2011
Installed CPU	No CPU Installed
Max Processors	2

Chipset
North Bridge	Intel C612

Memory Supported
Memory Slots	16 x 288Pin
Installed Memory Size	No Memory Installed
Max Memory Supported	Up to 1TB ECC LRDIMM, 512GB ECC RDIMM
Memory Type Supported	DDR4 2133/1866/1600
ECC Supported	Yes
Registered	Yes

Storage Supported
Installed HDD	No Storage Installed
Serial ATA	6x SATA3 (6Gbps) ports 2x SATA3 (6Gbps) ports onboard 2x SATA3 powered ports that support SATA DOM
SATA RAID	RAID 0/1/5/10

Graphics
GPU/VPU	ASPEED AST2400 BMC

Expansion Slots
PCI Express	3x PCI-E 3.0 x16 (Low-profile) 3x PCI-E 3.0 x8 (Low-profile)

Communications
First LAN	Intel X540
Second LAN	Intel X540
Max. LAN Speed	Dual 10 Gigabit

Expansion Bays
Hot-Swap Bays	6x 3.5" Hot-swap SATA HDD trays

Panel Ports
COM	1
VGA	1
Rear USB	2 x USB 3.0 2 x USB 2.0
RJ45	2x RJ45 10GBase-T LAN ports 1x RJ45 Dedicated IPMI LAN port
Other Ports	2x SuperDOM (Disk on Module) ports

Power Supply
Max. Power	650W

Features
Features	- Cloud and Virtualization needs - Compute Intensive Application - Database Processing and Storage - High Availability Storage - Mission-critical Applications 1. Dual socket R3 (LGA 2011) supports Intel Xeon processor E5-2600 v3 family; QPI up to 9.6GT/s 2. Up to 1TB ECC DDR4 2133MHz; 16x DIMM sockets 3. 3 PCI-E 3.0 x16, 3 PCI-E 3.0 x8 slots 4. Intel X540 Dual port 10GBase-T 5. Intel C612 controller for SATA3 ports; RAID 0, 1, 5, 10 6. 6x 3.5" Hot-swap SATA3 HDD Bays 7. 650W High-efficiency Power Supply Gold Level

Details
Form Factor	2U Rackmount

Dimensions & Weight
Dimensions	3.5" (89mm) x 19" (490mm) x 27" (680mm) (H x W x D)
Weight	31 lbs (14.2 kg)
