SUPERMICRO SYS-E102-9AP-L 3.5" SBC Server Barebone FCBGA 1296 DDR3L up to 1866 MHz (8GB)
- FCBGA 1296
- Intel Atom Processor E3930
- Single Socket FCBGA 1296 supported
- CPU TDP support 65W
- Lockable 12V DC 40W power adapter
+
+
Specs
Reviews
Learn more about the Supermicro SYS-E102-9AP-L
| Best Seller Ranking | #46 in Server Barebones |
|---|
| Brand | SUPERMICRO |
|---|---|
| Model | SYS-E102-9AP-L |
| Form Factor | 3.5" SBC |
| Workload | Edge Server |
| CPU Type | Intel Atom Processor E3930 Single Socket FCBGA 1296 supported CPU TDP support 65W |
|---|---|
| CPU Socket | FCBGA 1296 |
| Max Memory Supported | Up to 8GB Unbuffered non-ECC SO-DIMM, DDR3L-1866 MHz, in 1 x DIMM slot |
|---|---|
| Memory Type Supported | DDR3L up to 1866 MHz (8GB) |
| PCI Express | 1 x Full size Mini-PCIe (1 x USB 2.0, 1 x PCIe Gen2) |
|---|
| Number of LAN | Dual LAN with Intel I210IT |
|---|
| Max. Power | Lockable 12V DC 40W power adapter |
|---|
| Features | Intel Atom processor E3930 (6.5W, 2C) Single socket FCBGA 1296 System on Chip 1 x M.2 B-Key 2280, 1 x Full size Mini-PCI-E Up to 8GB unbuffered non-ECC SO-DIMM, DDR3L-1866 MHz, in 1 x socket Dual GbE LAN w/ Intel i210IT 4 x COM (RS-232/422/485), 2 x USB 3.0, 4 x USB 2.0 1 x VGA port, 1 x HDMI port Passive CPU heat sink and 1 x 40mm chassis fans Lockable 12V DC 40W power adapter |
|---|
| Dimensions | 1.72" x 7.48" x 4.72" |
|---|---|
| Weight | 2.65 lbs. |
| Date First Available | March 05, 2019 |
|---|
