SUPERMICRO SYS-E300-9C Compact Server Barebone LGA 1151 Intel Q370 DDR4-2666 MHz Unbuffered non-ECC SO-DIMM
- LGA 1151
- Intel Core i7 / i5 / i3 / Pentium / Celeron
- 150W DC Power Adapter
Specs
Reviews
Any questions? Our AI beta will help you find out quickly.
Try me now
Learn more about the Supermicro SYS-E300-9C
| Brand | SUPERMICRO |
|---|---|
| Model | SYS-E300-9C |
| CPU Type | Intel Core i7 / i5 / i3 / Pentium / Celeron |
|---|---|
| CPU Socket | LGA 1151 |
| North Bridge | Intel Q370 |
|---|
| Max Memory Supported | Up to 32GB Unbuffered non-ECC SO-DIMM, DDR4-2666 MHz |
|---|---|
| Memory Type Supported | DDR4-2666 MHz Unbuffered non-ECC SO-DIMM |
| Serial ATA | 5 x SATA 600 |
|---|
| GPU/VPU | 3 x Independent Displays |
|---|
| PCI Express | 1 x PCI-E 3.0 x16 |
|---|
| Number of LAN | Single LAN with Intel Ethernet Controller I210-AT Single LAN with Intel PHY I219LM LAN controller |
|---|
| RJ45 | 2 x RJ45 Gigabit Ethernet LAN ports |
|---|
| Max. Power | 150W DC Power Adapter |
|---|
| Features | Single Socket H4 (LGA 1151) supports: 8th Generation Intel Core i7 / i5 / i3 / Pentium / Celeron processor Intel Q370 chipset 2 x Internal 2.5" drive bays (Top drive bay area can accommodate either an AOC with riser card and bracket or 2.5" drive on the top bracket.) Up to 32GB unbuf. non-ECC SO-DIMM, DDR4-2666 MHz; in 2 x DIMM slots 1 x PCI-E 3.0 x16 LP AOC slot, M.2 M key: PCI-E 3.0 x4, support 2242/2280; M.2 E KEY: PCI-E 3.0 x1, support 2230 2 x 1 GbE LAN ports 4 x USB 3.1 (2 type A and 2 type C) 1 x HDMI, 1 x DP, 1 x DVI-D, HD Audio 2 x 4cm high performance PWM fans DC Power Adapter |
|---|
| Form Factor | Compact |
|---|
| Dimensions | 1.70" x 10.00" x 8.90" |
|---|---|
| Weight | 3.45 lbs. |
| First Listed on Newegg | December 03, 2018 |
|---|
