|Type||VGA Block & Cooler|
|Block Compatibility||The MCW60 is shipped with three separate retention mechanisms composed of spring loaded screws and back plates providing off-the-shelf compatibility with all ATI Radeon and most nVidia GeForce families of products as follows: |
1. Pre-assembled retention mechanism using the four holes surrounding the processor:
Most high-end nVidia GeForce series from 6800 and above (incl. latest 7900 series).
ATI Radeon series from X1800 and above (incl. latest X1900 series) - Please note that Master cards for Crossfire Systems feature a compositing chip requiring an extra MC14 heatsink for cooling, not provided with the kit.
Compatibility of nVidia: 8800 series,7900 GTX Series,7900 GT Series,7800 GT Series,7600GT Series,6800 XT Series,6800 GT Series,6800 GS Series,6800 Series
2. Retention mechanism for all ATI Radeon 7000 to X850, and X1300 to X1600 (*) series using the two alternate mounting holes.
X1600XT Series Note: Depending on the circuit board maker, some X1600XT are not compatible.
3. Retention mechanism for nVidia GeForce 8800 series
Earlier mid-range GeForce series (6600 and below) utilizing two diagonal mounting holes (3.12" spacing as shown below) require the optional MCW60-FX kit.
|Date First Available||February 02, 2007|
