Multi-mode IEEE1284 Compliant Controller (SPP, PS2, EPP, ECP). Faster Data Rates up to 1.5Mbps for Parallel Port
Utilize 100-MHz Differential PCI Express Common Reference Clock
Fully Compliant with PCI Express Base Specification, Revision 1.0a
PCIe Multi Function Peripheral Controller with x1 Lane Interface. Support PCIe Power Management
Support for D1, D2, D3hot and D3cold
Notes: Does not support Remap on I/O Address and IRQ
+
+
Overview
Specs
Reviews (4)
Part Number: SI-PEX10010 Based on WCH382l chipset, which adds a legacy Parallel port to computer for external peripheral device such as printer, and industrial automation applications, which keeps old printer running.Fully Compliant with PCI Express Base Specification, Revision 1.0aPCIe Multi Function Peripheral Controller with x1 Lane InterfaceSupports D1, D2, D3hot and D3coldUtilizes 100-MHz Differential PCI Express Common Reference ClockSupports PCIe Power ManagementSupports SPP, Nibble, Byte, PS/2, EPP, ECP, and other IEEE1284 parallel / printer port workSupports Bi-directional Data TransferSupports up to 1M Bytes/sec Transfer Rate===Notes:Does not support Remap on I/O Address & IRQ
Syba SI-PEX10010 1 Port Parallel DB25 PCI-e 1.0 x1
The Syba SI-PEX10010 is a single-port parallel adapter that is compatible with systems that have x1, x4, x8, or x16 PCI Express expansion slots. The card is designed for standard and low-profile PCs and servers and ships with a low-profile and a standard-height bracket. Based on WCH382l chipset, which adds a legacy parallel port to a computer for an external peripheral device such as printer, and industrial automation applications, which keeps an old printer running.
Specification
WCH382l chipset
Fully Compliant with PCI Express Base Specification, Revision 1.0a
Supports D1, D2, D3hot and D3cold
Utilizes 100-MHz Differential PCI Express Common Reference Clock
Supports SPP, Nibble, Byte, PS/2, EPP, ECP, and other IEEE1284 parallel / printer port work
Supports Bi-directional Data Transfer
Supports up to 1M Bytes/sec Transfer Rate
What's in the Box
1 Port Parallel PCI-e Controller Card
Driver CD
User Manual
Low Profile Bracket
Learn more about the Syba SI-PEX10010
Model
Brand
SYBA
Model
SI-PEX10010
Details
Type
PCI Express to Parallel Port
External Ports
1 x Parallel Port
Operating Systems Supported
Windows 7 Windows Vista Windows XP Server 2012 Server 2008 Server 2003 Server 2000(32bit only) Windows ME Windows 98SE Windows 98 Linux Kernel 2.4 & 2.6 Mac 10.4 & above
Features
Features
Fully Compliant with PCI Express Base Specification, Revision 1.0a
PCIe Multi Function Peripheral Controller with x1 Lane Interface
Supports D1, D2, D3hot and D3cold
Utilizes 100-MHz Differential PCI Express Common Reference Clock
Supports PCIe Power Management
Supports SPP, Nibble, Byte, PS/2, EPP, ECP, and other IEEE1284 parallel / printer port work
Supports Bi-directional Data Transfer
Supports up to 1M Bytes/sec Transfer Rate
Notes: Does not support Remap on I/O Address & IRQ
Packaging
Package Contents
1-port Parallel PCI-e Controller Card Driver CD User Manual Low Profile Bracke
Additional Information
Date First Available
September 12, 2023
