Question 1

How many fans does this come with?

Accepted Answer

2 fans. They're the quietest fans I've ever experienced. If you buy more (there's room for three more) make sure they're the same one for consistent quiet.

Question 2

Can you mount a large cpu cooler such as a cooler master evo 212, what are the limitations?

Accepted Answer

Yep, it has a deep case design with an additional vertical extension slot that will allow for oversized cooling solutions. Although personally I took advantage of the liquid cooling option and top mount radiator design, which is far superior in terms of sound levels and efficiency.

Question 3

Does the bottom of the case include a dust filter for the optional 120mm fan?

Accepted Answer

There are tabs on the bottom that look like it would hold a filter like the PSU fan has but mine didn't come with one. Also looking at the pictures it doesn't look like there is a filter used in those.

Question 4

Would this be able to fit a MSI GTX 1070? I've done a bit of research but I've found that the case only supports cards up to 410mm long but anything over 270mm will block drive bays and the graphics card is 279mm, would the card be an issue with this case?

Accepted Answer

It can fit if you're willing to remove some drive bays, but could be an issue if you wanted to keep all the drive bays. I have a graphics card that is 294mm and I was able to fit it into the case by simply removing the top three bays (there was no way it would fit without removal). Removal of those three bays was simple (I think I just slid out the metal frame that holds them).

Question 5

Are you able to use a 3.5 drive for a 2.5 in ssd without a mounting kit?

Accepted Answer

I do not think you can install a smaller drive into a larger space without using some reducing kit. I dont see anything inside the case itself that will permit that.

Question 6

Reading the specs it says you can install a 200mm fan on top. But looking at the pictures it does not look like it has the mounting hole for such a big fan. Can anyone confirm it a 200 mm will fit in the top? Thanks

Accepted Answer

In my opinion, no. There are mounting holes for a 200mm fan, but the top is stepped so that a 200 mm fan will not fit in the perforated fan area, which is 193mm wide at the top and 200 mm wide at the base . It is sloped like a pyramid. The entire top is 220mm wide.  You can see the edge of the step-up in the picture.  However, I have not actually tried to fit a 200mm fan in my unit.

Question 7

Does it come with the hardware to convert one of the 5.25" to a 3.5"?
My client wants a card reader in there as well as 2 DVD units.

Accepted Answer

It does not have a conversion bay however there is a 5.25" sd card reader that comes with additional reading accessories somewhere between I think 20 - 30 dollars.

Question 8

I can see that there is a vertical GPU mounting slot on the back of they case, but can't tell if it is a single or double PCIe slot.   Does anybody know?

Accepted Answer

Single, 5th picture

Question 9

What's the biggest cpu fan I can put in here? A 120mm or a 140mm? The biggest I was thinking of getting was the Phantek 140mm CPU cooler (http://www.newegg.com/Product/Product.aspx?Item=35-709-001)

Accepted Answer

Yes, Justin C. You will be able to fit a 140mm cooler in there.  I've had a 120mm Zalman (152mm tall) and there is about 2-3 inches between the top of my cooler and the side door, your cooler is only 159mm tall, so yes it will fit.
On the other hand, you must check if you will have enough clearance at the bottom of you cooler since it is pretty long (171mm).  Chances are a transistor, chipset heat sink, or your memory heat sink will stick up high and get in the way of the cooler, preventing it from sitting properly on your CPU.
Best of luck.

Question 10

Will this case allow me to fit a full atx board and 240mm radiator at the top?

Accepted Answer

A full ATX motherboard will fit inside the case. Concerning the radiator, the top of the case supports maximum dimensions 140mm x 240mm
