Question 1

does it come with all the parts or do i have to buy them myself?

Accepted Answer

I'm not sure what you mean, but it's a modular case with drive bays and couple of case fans. The last picture pretty much shows you what is in the box. You can also checkout YouTube videos of this being unboxed and reviewed. Geared towards those whom want to liquid cool and customize a pc build.

Question 2

If I use a 360mm AIO CPU cooler made by a popular brand like Corsair or Cooler Master, will it only fit in the front of the case? (To attach to the motherboard) I know there is room in the back of the case for big radiators but it looks like there is no room to push the waterblock mount of the AIO CPU cooler from the back of the case to the front of the case (Unless you make a custom liquid loop). So will pre-built AIOs by Corsair/Cooler Master/etc. only fit in the front of the case to work?

Accepted Answer

I ordered this case on 12/15/2017 to do a hard line build and had issues with the fan to rad mounting bracket causing the fan blades to hit the metal bracket without nylon spacers on the screws. If your GPU is not water-cooled also you might have overheating, I have two EVGA 1080ti Kingpin cards and both were overheating during testing as there is not a lot of airflow in the front of this case as there is one fan mount in the top of the case and one to cool the HDD area. To answer your question I would say this case is designed for a complete hardline water cooling build and not for AIOs. In my opinion, I would look into the phanteks line of cases. I have the ENTHOO ELITE which my hard line build will be going in, I also have the ENTHOO EVOLV X which in my opinion would be a great option for you as this case has great build quality and works with any AIO and air cooling like the Noctua NH D15 if you go the air cooling route. To newegg, you silence the last answer you asked me to give and if you delete this on we are going to have issues.

Question 3

How many 140mm fans could you fit?

Accepted Answer

Thirteen. There are two fans delivered on top. The center hard drive rack can have a fan mounted above. Two fans can be mounted on back panel. Four fans can be mounted on each rear side panel to cool radiators.

Question 4

In the manual on Page 10, it appears there are 5 different placement options for drive cages on each side.

If one were able to acquire a total of 10 drive cages, would it be possible to place all of them for a total of 20 drives?

Accepted Answer

I answered this question earlier, but I need to add some information.  Theoretically, a person could put 10 cages in, but practically, the power supply would be in the way for the bottom two cages.  There is a total of 14 3/4 inches width between the sides of the mounting points for the drive cages, and nothing in the way for the eight you could mount above the power supply.  I am thinking of trying to cram a couple of icy dock FatCage MB155SP-B hot-swap hard drive cages in mine.  They hold five per unit, but only handle up to 6 terabyte drives.  Unfortunately, they are 7.9 inches long, so they cannot be mounted on opposing sides.

Question 5

how many duel slot graphics cards can it support?

Accepted Answer

It's huge.  As many as your motherboard can take and your power supply can handle. I couldn't find a mother board that would allow me to place more than 4 dual cards in it, although it does have 8 PCI-e 8/16x slots. The case can handle a much larger motherboard, I couldn't find any though.

Question 6

where is the blu ray burner slot at ?

Accepted Answer

There is a 5.25 slot at the bottom front of the case. I do not think it's intended for a cd/dvd/bluray/typical 5.25 peripheral. But it could certainly be modified to fit one. Wait for more answers or search google

Question 7

will 120x120x38mm fans fit at the top?

Accepted Answer

Yes. The stock fans are 140mm but the case has holes for 120mm fans. 38mm should be no problem unless you plan on running a very wide (80mm) radiator as high as it will mount in the back.

Question 8

Does this support a x299 motherboard? im guessing it does but just checking

Accepted Answer

It should, I used a 9.6" x 9.6".  it says it supports the following:
 6.7” x 6.7” (Mini ITX)
9.6” x 9.6” (Micro ATX)
12” x 9.6” (ATX)
12” x 13” (E-ATX)

Question 9

Just wondering if this case comes with the liquid cooling?

Accepted Answer

Hi.  it does not come with any Liquid cooling.   you will have to add rads,
it does come with a couple fans.

Question 10

how is the air flow or do you need to have water cooling?

Accepted Answer

air flow is pretty good you can use water cooling or air cooling fans to keep your cpu cooler
