WiFi Generation | Wi-Fi 6 |
---|
Wireless Standard | IEEE 802.11a / IEEE 802.11ac / IEEE 802.11ax / IEEE 802.11b / IEEE 802.11g / IEEE 802.11n |
---|
Security | SPI Firewall Access Control IP & MAC Binding Application Layer Gateway |
---|
WPA | WEP, WPA, WPA2, WPA/WPA2-Enterprise (802.1x) |
---|
WAN Ports | 1 x 10/100/1000M; 1 x 2.5G |
---|
LAN Ports | 3 x 10/100/1000M |
---|
Buttons | Wi-Fi On/Off Button Power On/Off Button LED On/Off Button WPS Button Reset Button |
---|
Wireless Data Rates | AX6600 / Up to 6.6Gbps |
---|
Frequency Band | 2.4 GHz / 5 GHz / 5 GHz |
---|
Antenna | 8x Detachable High-Performance Antennas |
---|
Transmitted Power | CE: <20dBm (2.4GHz) <23dBm (5.15GHz~5.35GHz) <30dBm (5.47GHz~5.725GHz) FCC: <30dBm (2.4GHz & 5.15GHz~5.25GHz & 5.725GHz~5.825GHz) <24dBm (5.25GHz-5.35GHz & 5.47GHz-5.725 GHz) |
---|
Receiver Sensitivity | 5 GHz-1: 11a 6Mbps:-93dBm, 11a 54Mbps:-76dBm 11ac VHT20 MCS0:-92dBm, 11ac VHT20 MCS8:-69dBm 11ac VHT40 MCS0:-90dBm, 11ac VHT40 MCS9:-65dBm 11ac VHT80 MCS0:-87dBm, 11ac VHT80 MCS9:-62dBm 11ax HE20 MCS0:-93dBm,11ax HE20 MCS11:-62dBm 11ax HE40 MCS0:-90dBm,11ax HE40 MCS11:-59dBm 11ax HE80 MCS0:-87dBm,11ax HE80 MCS11:-56dBm 5 GHz-2 (Gaming Band): 11a 6Mbps:-96dBm, 11a 54Mbps:-77dBm 11ac VHT20 MCS0:-95dBm, 11ac VHT20 MCS11:-64dBm 11ac VHT40 MCS0:-93dBm, 11ac VHT40 MCS11:-62dBm 11ac VHT80 MCS0:-90dBm, 11ac VHT80 MCS11:-59dBm 11ac VHT160 MCS0:-84dBm, 11ac VHT160 MCS11:-53dBm 11ax HE20 MCS0:-93dBm,11ax HE20 MCS11:-62dBm 11ax HE40 MCS0:-90dBm,11ax HE40 MCS11:-59dBm 11ax HE80 MCS0:-87dBm,11ax HE80 MCS11:-57dBm 11ax HE160 MCS0:-84dBm,11ax HE160 MCS11:-54dBm 2.4 GHz: 11g 6Mbps:-96dBm, 11g 54Mbps:-77dBm 11n HT20 MCS0:-95dBm, 11n HT20 MCS7:-76dBm 11n HT40 MCS0:-93dBm, 11n HT40 MCS7:-73dBm 11ac VHT20 MCS0:-95dBm, 11ac VHT20 MCS8:-73dBm 11ac VHT40 MCS0:-92dBm, 11ac VHT40 MCS9:-68dBm 11ax HE20 MCS0:-95dBm,11ax HE20 MCS11:-64dBm 11ax HE40 MCS0:-95dBm,11ax HE40 MCS11:-62dBm |
---|
Operation Mode | Access Point Mode / Wireless Router Mode |
---|
Interface | 1 x USB 3.0 Port 1 x USB 2.0 Port |
---|
VPN support | OpenVPN, PPTP |
---|
Processor | 1.5 GHz Quad-Core CPU |
---|
System Requirements | Internet Explorer 11+, Firefox 12.0+, Chrome 20.0+, Safari 4.0+, or other JavaScript-enabled browser
Cable or DSL Modem (if needed)
Subscription with an internet service provider (for internet access) |
---|
Dimensions | 2.00" x 8.30" x 8.30" |
---|
Temperature | Operating Temperature: 0°C~40°C (3°F ~104°F) Storage Temperature: -40°C~70°C (-40°F ~158°F) |
---|
Humidity | Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing |
---|
