TP-LINK CAP300 300 Mbps Wireless N Ceiling Mount Access Point

Specs

Reviews

Any questions? Our AI beta will help you find out quickly.

Try me now

Learn more about the TP-Link CAP300

Model
Brand	TP-Link
Model	CAP300

Details
Standards	IEEE 802.11n, IEEE 802.11g, IEEE 802.11b
Wireless Data Rates	Up to 300Mbps
Security	Captive Portal Authentication Access Control Mac Address Authentication Wireless Isolation Between Clients SSID to VLAN Mapping WPA / WPA2-Enterprise, WPA-PSK / WPA2-PSK
Frequency Band	2.4 GHz - 2.4835 GHz
Antenna	Internal 2 x 3dBi Omni
Transmitted Power	CE: <20 dBm FCC: <26 dBm
Receiver Sensitivity	300M: -71 dBm @ 10% PER 150M: -75 dBm @ 10% PER 54M: -78 dBm @ 10% PER 11M: -93 dBm @ 8% PER 6M: -92 dBm @ 10% PER 1M: -96 dBm @ 8% PER
System Requirements	Microsoft Windows 10 / 8 / 7 / Vista / XP
Interface	1 x Fast Ethernet (RJ-45) Port (Support IEEE802.3af PoE)
Buttons	Reset, FIT / FAT
Power Supply	Power Supply : PoE or external 9V DC / 0.6A power supply Power Consumption: 5W

Environmental
Temperature	Operating Temperature: 0 degree C ~ 40 degree C (32 degree F ~ 104 degree F) Storage Temperature: -40 degree C ~ 70 degree C (-40 degree F ~ 158 degree F)
Humidity	Operating Humidity: 10% ~ 90% non-condensing Storage Humidity: 5% ~ 90% non-condensing

Dimensions & Weight
Dimensions	1.90" x 7.10" x 7.10"

Features
Features	Hardware wireless controller enable administrators to easily manage hundreds of CAPs Support Power over Ethernet (802.af) for convenient and affordable installation Simple mounting design for easy attachment to a wall or ceiling Captive portal provides on convenient method of authentication for Wi-Fi guests Enterprise class Wi-Fi security help to decrease network security threats Multi-SSID divides multiple wireless networks for different user types FAT / FIT mode switchable provides a range of network possibilities

Packaging
Package Contents	300 Mbps Wireless N Ceiling Mount Access Point CAP300 Power Adapter Mounting Kits Installation Guide
