Standards | IEEE 802.11ac |
---|
Frequency Band | 2.4 GHz / 5.0 GHz |
---|
Wireless Data Rates | Up to 1.3Gbps |
---|
Security | 64/128-bit WEP, WPA-PSK / WPA2-PSK |
---|
WPA/WPA2 | WPA2 |
---|
Antenna | 3 x External |
---|
Transmit Power | <20 dBm (2.4 GHz) <23 dBm (5 GHz) |
---|
Receiving Sensitivity | 5 GHz: 11a 6 Mbps: -93 dBm@10% PER 11a 54 Mbps: -76 dBm@10% PER 11ac HT20 mcs8: -68 dBm@10% PER 11ac HT40 mcs9: -64 dBm@10% PER 11ac HT80 mcs9: -61 dBm@10% PER
2.4 GHz 11g 54 Mbps: -77 dBm@10% PER 11n HT20 mcs7: -73 dBm@10% PER 11n HT40 mcs7: -70 dBm@10% PER |
---|
Interface | Ethernet Port |
---|
Ports | 1 x 10/100/1000M |
---|
Button | RE (Range Extender) Button, Reset Button, LED Button, Power Button |
---|
System Requirements | Microsoft Windows 98SE, NT, 2000, XP, Vista or Windows 7, 8, 10, Mac OS, NetWare, UNIX or Linux. |
---|
Dimensions | 6.40" x 3.00" x 2.60" |
---|
