TRIPP LITE B024-H4U16 16-Port 4K HDMI/USB KVM Switch - 4K 60 Hz Video/Audio, USB Peripheral Sharing, 1U Rack-Mount
- Supports true 4K resolutions up to 4096 x 2160 (@ 60 Hz) for crystal-clear video
- Cascade up to 2 levels to control as many as 256 computers from a single console
- 2-port USB 3.2 Gen 1 hub lets you share USB peripherals among connected computers
- Push buttons, hotkeys and on-screen display allow easy toggling between computers
- Widely compatible KVM switch works with Windows, Mac and Linux operating systems
Specs
Reviews
Any questions? Our AI beta will help you find out quickly.
Try me now
Learn more about the Tripp Lite B024-H4U16
| Brand | TRIPP LITE |
|---|---|
| Model | B024-H4U16 |
| Type | HDMI; Stereo Audio; USB 3.x |
|---|---|
| Console Connectors | Number of Ports: 16 PC/Server Connections: HDMI Side A - Connector 1: HDMI (FEMALE) Side A - Connector 2: (2) USB A (FEMALE) Side A - Connector 3: 3.5MM (FEMALE) Side B - Connector 1: (16) HDMI (FEMALE) Side B - Connector 2: (16) USB B (FEMALE) Side B - Connector 3: (16) 3.5MM (FEMALE) Computer Keyboard and Mouse Interface: USB Computer Monitor Interface: HDMI |
| Video Resolution | Max Supported Video Resolution: HDMI: 4096 x 2160 @ 60Hz |
| LED Indicators | Orange x16 (Selected Port); Green x1 (Power); Green x16 (USB Link) |
| Temperature | Operating Temperature Range: 32 to 104 F (0 to 40 C) Storage Temperature Range: -4 to 140 F (-20 to 60 C) |
|---|---|
| Humidity | 0 to 80% RH, Non-condensing |
| Audio Features | 2.1-channel surround sound audio |
|---|---|
| Power Features | External Power Supply Input Specs (V / Hz / A): 100-240V, 50/60Hz, 1.4A External Power Supply Output Specs (V / A): 12V / 5A External Power Supply Cord Length (ft.): 4 External Power Supply Cord Length (m.): 1.2 DC Barrel Plug: OD: 5.5 x 2.5 x 9.5mm, Positive Pin, Negative Sleeve Power Consumption (Watts): 9.77 External Power Supply Plug(s): BS 1363 UK; IEC-320-C14; NEMA 1-15P North America |
| Features | Connects 16 HDMI-Enabled Devices to a Single 4K Monitor, Keyboard and Mouse This rack-mount KVM switch lets you access, control, boot and reboot up to 16 computers or other devices with 4K HDMI ports at the same time. In addition to desktop and notebook computers, the switch also connects up to 16 4K media centers, gaming systems, Blu-ray and DVD players, cable and satellite boxes, DVRs and other HDMI-enabled devices. All 16 computers share one 4K HDMI monitor, USB keyboard and USB mouse, which saves space on your desk or workspace. Connect up to 256 Computers to One Original Console You can also cascade up to two levels of B024-H4U16 KVM switches, allowing centralized access to as many as 256 computers using a single monitor, keyboard and mouse. Switching Between Computers Is Fast and Easy Use the front-panel push buttons, hotkey commands or multi-lingual On-Screen Display (OSD) with text-based interface for quick and easy toggling between computers. Or you can use Auto Scan mode to scan all connected computers in five-second intervals automatically. Orange LEDs indicate which computer is currently selected. Cables Are Included for Fast and Simple Setup Connect your 4K HDMI monitor, keyboard, mouse, and speakers to the switch's console ports. Then, use the included 4K HDMI/USB KVM cable kits to connect your computers to the KVM switch. The plug-and-play B024-H4U16 requires no drivers, so you can connect and use it immediately. It works with all major operating systems, including Windows, Mac, Linux, UNIX and Novell. USB Hub Lets You Share Peripherals between Computers The built-in USB 3.2 Gen 1 hub allows you to share two USB-A peripherals, such as printers, hard drives, scanners, webcams and flash drives, between all connected computers. Both USB ports support data transfer speeds up to 5 Gbps. Because the USB ports operate independently, you can print documents from one computer while working on a different computer. |
| Dimensions | 17.02" x 8.44" x 1.73" |
|---|---|
| Weight | 7.80 lbs. |
| Package Contents | B024-H4U16 16-Port HDMI/USB KVM Switch, 1U (2) 4K HDMI/USB KVM cable kits, 6 ft. Firmware upgrade cable, 6 ft. External power supply (Input: 100–240V, 50/60 Hz, 1.4A; Output: 12V 5A) (3) International power cords (North America, Europe, U.K.) (4) Rubber feet Rack-mounting hardware Quick Start Guide |
|---|
| First Listed on Newegg | June 09, 2022 |
|---|
