TYAN B7016G24V4H 1U Rackmount Server Barebone Dual LGA 1366 Intel 5520 DDR3 1333/1066/800
- Dual LGA 1366
- Dual Intel Xeon 5500 Series
- 18 x 240Pin Memory Slots
- EPS1U 600W (80+)
Specs
Reviews (3)
Any questions? Our AI mode will help you find out quickly.
Try me now
Learn more about the TYAN B7016G24V4H
| Brand | TYAN |
|---|---|
| Model | B7016G24V4H |
| Form Factor | 1U Rackmount |
| CPU Type | Dual Intel Xeon 5500 Series |
|---|---|
| CPU Socket | Dual LGA 1366 |
| North Bridge | Intel 5520 |
|---|---|
| South Bridge | ICH10R |
| Memory Slots | 18 x 240Pin |
|---|---|
| Memory Type Supported | DDR3 1333/1066/800 |
| Channel Supported | Triple Channel |
| SATA RAID | RAID 0/1/10/5 (Intel Matrix RAID) |
|---|
| GPU/VPU | ServerEngines Pilot2 |
|---|
| PCI Express | 1 x PCI-E Gen.2 x16 slot 1 x PCI-E Gen.2 x8 slot |
|---|
| First LAN | Intel 82574L / Intel 82576EB |
|---|---|
| Max. LAN Speed | 1 Gigabit |
| Slim Bays | 1 |
|---|---|
| Hot-Swap Bays | 4 x 3.5" SATA II |
| Front USB | 2 |
|---|---|
| COM | 1 |
| PS/2 | 2 |
| VGA | 1 |
| Rear USB | 2 |
| RJ45 | 3 |
| Max. Power | EPS1U 600W (80+) |
|---|
| Features | Pre-install TYAN Riser Card : M2083-RS, PCI-E x16 1U riser card (left) / M2081-2, PCI-E x8 1U riser card (right) |
|---|
| Dimensions | 25.4" x 17.2" x 1.72" |
|---|---|
| Weight | 35.27 lbs. |
| First Listed on Newegg | November 05, 2009 |
|---|
