Package Contents

DJI Agras T40 Power Distribution Board × 1

Product Overview

The DJI Agras T40 Power Distribution Board is a critical high-power distribution module designed exclusively for the DJI Agras T40 agricultural drone. It ensures stable and efficient power delivery to key systems (motors, ESCs, spray pumps, and flight controllers) during precision agriculture operations such as crop spraying and fertilization. Engineered for durability in harsh environments, this board is essential for maintaining optimal drone performance in plant protection tasks.

Key Parameters

Compatibility

Model-Specific: Only for DJI Agras T40 (Firmware-optimized; not compatible with T20/T30/T40 Advanced/T70).

Mounting Interface: Standardized 8-pin aviation-grade connector (Precision alignment for tool-free installation).

Electrical Specifications

Input Voltage: 12S LiPo Battery (44.4V nominal, 50.4V max under load).

Output Channels: 6x independent power circuits (12V/24V/48V adaptive switching).

Current Capacity: 30A per channel (Continuous), 60A peak (10-second surge for motor startup).

Protection Features: Overcurrent, overvoltage, undervoltage, short-circuit, and reverse-polarity protection.

Agricultural Application Features

Spray Pump Power Support: Dedicated 12V/5A output for high-flow spray pumps (Ensures consistent liquid delivery).

ESC Stability: Precision voltage regulation for electronic speed controllers (Minimizes motor vibration during flight).

Load Balancing: Dynamic power distribution to prevent overloading individual circuits (Optimized for multi-tasking operations).

Hardware Design

Material: High-temperature aerospace aluminum alloy base + flame-retardant polycarbonate casing.

Protection Rating: IP54 (Dust-resistant and splash-proof for field operations).

Operating Temperature: -10°C to 50°C (14°F to 122°F; Adaptable to diverse climates).

Weight: Approx. 150g (Including connectors and protective coatings).

Functional Features

Real-Time Monitoring: Voltage/current feedback to the drones flight controller (Enables proactive power management).

Auto-Calibration: Self-adjusts for battery voltage fluctuations (Ensures stable output during long flights).

Quick-Disconnect: Modular connectors for rapid maintenance or replacement.

Software Integration

DJI Pilot 2 App: Displays power board status (Voltage, current, and fault alerts) via the drones telemetry system.

Firmware Updates: Requires DJI authorized tools for updates (Ensures compatibility with new agras features).

Certifications & Compliance

CE / FCC / RoHS Certified (Meets international safety and electromagnetic standards).

DJI OEM Approved (Guaranteed reliability and compatibility with Agras T40).

Installation & Maintenance

Installation Steps:

Power off the Agras T40 drone and disconnect the battery.

Remove the old power board (If replacing) and clean the mounting area.

Align the new board with the 8-pin connector and secure with mounting screws.

Reconnect all cables (Follow the wiring diagram in the quick-start guide).

Test power distribution with a low-power flight before full operation.

Maintenance Tips:

Inspect connectors for corrosion or looseness every 20 flight hours.

Clean the board surface with compressed air to remove dust/debris.

Store in a dry, temperature-controlled environment when not in use.

Notes

Compatibility Reminder: Strictly for DJI Agras T40. Using it on other models will cause malfunctions or damage.

Firmware Requirement: Ensure the drone runs the latest firmware for optimal power board performance.

Safety Warning: Never disassemble the board or modify internal circuits (Risk of electric shock or voiding warranty).
